17
GB
Important. Carry out a trial cut in a piece of
waste wood
6.4 Changing the saw blade (Fig. 1/7-8)
Important. Always pull out the power plug
before doing any work on the circular saw!
Only use saw blades of the same type as the saw
blade supplied with this circular saw. Ask your dealer
for advice.
Important. The mini hand-held circular saw must not
be operated with the Allen key inserted in it.
Undo the screw for securing the saw blade (12)
by turning it in clockwise direction with the Allen
key (a) while at the same time holding on the
opposite side with the Allen key (b).
Press the locking button (3) and use the lever (5)
to raise the adjustable soleplate (6) and hold.
Remove the saw blade (7) in a downwards
direction.
Clean the flange and insert the new saw blade.
Pay attention to the running direction (see arrow
on the housing (c) and saw blade).
Tighten the screw to secure the saw blade (12),
check it runs true.
Before you press the On/Off switch, make sure
that the saw blade is correctly fitted and that
moving parts run smoothly and the clamping
screws are tightened securely.
6.5 Using the laser (Fig. 9-10)
The laser (15) enables you to make precision
cuts with your circular saw.
The laser light is generated by a laser diode. The
laser light is enlarged to form a line and is emitted
through the laser emission aperture. You can
then use the line as an optical marker for the
sawing line for precision cuts. Follow the laser
safety instructions.
You can switch the laser ON and OFF with the
ON/OFFswitch (14).
The laser beam may be affected by deposits of
dust and chips. The emission aperture of the
laser beam must therefore be cleaned after each
use.
Always switch off the laser when not in use.
Replacing the battery
Ensure that the laser is switched off. Remove the
battery compartment cover (a). Remove the flat
battery and replace with a new one (button cell
CR2032). Check that the battery terminals are
positioned correctly when inserting the new batteries.
Close the battery compartment again.
6.6 Replacing the drive belt (Fig. 11-12)
앬 The belt should be replaced by a trained expert.
앬 The drive belt (B) must be replaced if it is worn.
앬 Undo the screw (a) and remove side belt cover
(A).
앬 Remove the worn drive belt (B) and clean the two
belt pulleys (C/D).
앬 Place the new drive belt on the belt pulley (C) and
pull the belt onto the belt pulley (D) whilst turning
the shaft.
앬 Make sure that the drive belt is properly seated
on the belt pulleys.
앬 Fit the belt cover (A) and secure it with the screw
(a).
6.7 Reset button (Fig. 13)
In case of overloading, e.g. due to the saw blade
becoming jammed, the equipment will shut down
automatically. To restart, you must first press the
reset button (16). The equipment can then be
operated as normal.
7. Replacing the power cable
If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
8. Cleaning, maintenance and ordering
of spare parts
Always pull out the power plug before starting any
cleaning work.
8.1 Cleaning
Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
down with compressed air at low pressure.
We recommend that you clean the equipment
immediately after you use it.
Clean the equipment regularly with a damp cloth
and some soft soap. Do not use cleaning agents
or solvents; these may be aggressive to the
plastic parts in the equipment. Ensure that no
water can get into the interior of the equipment.
