SiBE121135_A Field Settings
Trial Operation and Field Settings 254
Caution Replace the PCB if you accidentally cut a wrong jumper.
Jumpers are necessary for electronic circuit. Improper operation may occur if you cut any of
them.
Floor Standing
Type
FVXG Series
(1) Remove the front panel, air filters and front grille.
(2) Remove the screw, and remove the service cover.
FTXG Series CTXS, FTXS20/25K
FTXS35/42/50K, FTXS-J, ATXS Series FTXS-G Series
JA
(Bottom of electrical box)
(R12036)
ADDRESS : JA
EXIST : 1
CUT : 2
JA
JB
JC
ADDRESS
1
2
JA
EXIST
CUT
(R16497)
ADDRESS
JA
(R12216)
JA
EXIST
CUT
ADDRESS
1
2
ADDRESS
ADDRESS:JA
(R11735)
JB
JA
JC
1
2
EXIST
CUT
Service cover
(R14629)
