Priority during "Powerful" operation
If the indoor unit which is set for priority-room is operating at
"Powerful" operation, distribution of capacity to other indoor units will
be reduced. This means that the room of which the indoor unit is set
for priority-room will be cooled or heated much quicker than other
rooms.
Indoor or outdoor unit quiet operation priority
Pressing the "Quiet operation button" on the remote controller of the
indoor unit set for priority-room, will make the outdoor unit run quietly.
You do not have to set all operated indoor units to outdoor unit quiet
operation in this case. Running units in outdoor unit quiet operation
however, reduces the cooling/heating capacity.
Setting procedure
Slide the switch to the ON side for the switch that corresponds to the
piping connected to the indoor unit to be set. (In the figure below, it is
room A.)
Once the settings are complete, reset the power.
NIGHT QUIET MODE SETTING
The night quiet mode setting requires initial programming during
installation. Explain night quiet mode, as described below, to the
customer, and confirm whether or not the customer wants to use
night quiet mode.
Night quiet mode function
The night quiet mode function reduces operating noise of the outdoor
unit at nighttime. This function is useful if the customer is worried
about the effects of the operating noise on the neighbours.
Running units in night quiet mode however, reduces the cooling/
heating capacity.
Setting procedure
Remove the SW5 jumper switch.
Once the settings are complete, reset the power.
COOL/HEAT MODE LOCK <S15> (HEAT
PUMP UNITS ONLY) (See figure 7 and arrow view A in this
paragraph)
Use the S15 connector to set the unit to only cool or only heat.
1 Setting to only heat (H): short-circuit pins 1 and 3 of the
connector S15.
2 Setting to only cool (C): short-circuit pins 3 and 5 of the
connector S15.
The following specifications apply to the connector housing and pins
(JST products):
Housing VHR-5N
Pin SVH-21T-1,1
Remark that bridging connections are available as spare parts.
Check the dedicated spare parts list.
Be sure to only set 1 room as priority-room.
A
1
2
3
4
S102
S2
S52
ABCD
ON
SERVICE MONITOR
1
1 Priority-room setting switch SW4
ABCD
ON
NOTE
Install the removed jumper switch as described below.
This switch will be needed to later disable this setting.
NOTE
Forced operation remains available, whatever the
mode setting that has been locked.
1
A
1
2
3
4
S102
S2
S52
ABCD
ON
SERVICE MONITOR
1 Night Quiet Mode setting switch SW5
21
1 Jumper switch
2 After removing
12
S15
135
A
