- 20 -

not connect the cooker hood exhaust to the same conductor

used to circulate hot air or for evacuating fumes from other

appliances generated by other than an electrical source.Before

proceeding with the assembly operations, remove the anti-

grease lter(s) (Fig.5A) so that the unit is easier to handle.

In the case of assembly of the appliance in the suction version

prepare the hole for evacuation of the air.

•We recommend the use of an air exhaust tube which has

the same diameter as the air exhaust outlet hole. If a pipe

with a smaller diameter is used, the efficiency of the product

may be reduced and its operation may become noisier.

•Fittingthecooker-hoodtothelowerpartofawallunit:

The appliance should be embedded into the wall unit or

another support. This process should be carried out by using

4 screws suitable for the kind of unit following the instructions

for the drilling of the holes as shown in (Fig.2).

Fix the cooker hood to the cabinet securely by using a

screwdriver to tighten the screws until the appliance is ush

with the cabinet (Fig.3).

If your product is tted with a connector ange, perform the

assembly steps indicated in Fig.4 before xing the cooker

hood to the structure.

Take connector ange N and t it to the upper part of the

cooker hood suction assembly using the 2 screws (Fig.4).

•Extractorversion:

When installed in this way the appliance expels fumes outside,

either through a perimeter wall or through existing ducting.

It is therefore necessary to purchase a non-ammable air

exhaust tube (not supplied) which complies with all current

legislation and connect it to ange N (Fig.1).

•Filterhood:

Please note!

The lters must be ordered from your dealer as an accessory.

- To transform the hood from the SUCTION version to the

FILTERING version, charcoal lters must be ordered from your

dealer as an accessory.

Two types of kit are available, one with non-renewable lters

(Fig.5B) and the other with renewable filters (washable)

(Fig.5C).

USE AND MAINTENANCE

•We recommend that the cooker hood is switched on before

any food is cooked. We also recommend that the appliance is

left running for 15 minutes after the food is cooked, in order

to thoroughly eliminate all contaminated air.

The eective performance of the cooker hood depends on

constant maintenance; the anti-grease lter and the active

carbon lter both require special attention.

•Theanti-greaselter is responsible retaining the grease

particles suspended in the air, therefore it is subject to clogging

with variable frequency according to the use of the appliance.

- To prevent the danger of possible fires, at least every 2

months one must wash the anti-grease lters by hand using

non-abrasive neutral liquid detergents or in the dishwasher

at low temperatures and on short cycles.

- After a few washes, colour alterations may occur. This does

not give the right to claim their replacement.

•Theactivecarbonlters are used to purify the air that is

sent back into the room and its function s to mitigate the

unpleasant odours produced by cooking.

- The non-regenerable active carbon lters must be replaced

at least every 4 months. The saturation of the active charcoal

depends on the more or less prolonged use of the appliance,

on the type of kitchen and on the frequency with which anti-

grease lter is cleaned.

- Regenerable active charcoal lters must be washed by hand,

with non abrasive neutral detergents, or in the dishwasher at

a maximum temperature of 65°C (the washing cycle must be

complete without dishware). Remove excess water without

damaging the lter, remove the plastic parts, and let the mat

dry in the oven for at least 15 minutes approximately at a

maximum temperature of 100°C. To keep the regenerable

charcoal lter functioning ecient this operation must be

repeated every 2 months. These must be replaced at least

every 3 years or when the mat is damaged.

•Beforeremountingtheanti-greasefiltersandthe

regenerableactivecharcoalltersitisimportantthatthey

arecompletelydry.

•Cleanthehoodfrequently,bothinternallyandexternally,

using a cloth dampened with denatured alcohol or neutral

liquid detergents that are non abrasive.

•The lighting .system is designed for use during cooking

and not for the prolonged general lighting of the room. The

prolonged use of the lighting system signicantly decreases

the average duration of the bulbs.

•If the appliance is equipped with courtesy lights it is possible

to use them for general room lighting for a prolonged amount

of time.

•Attention: The non compliance with the hood cleaning

warnings and with the replacement and cleaning of the lters

entails risk of res. One therefore recommends keeping to the

suggested instructions.

•Replacinghalogenlightbulbs(Fig.6.1):

To replace the halogen light bulbs B, remove the glass pane

C using a lever action on the relevant cracks.

Replace the bulbs with new ones of the same type.

Caution: do not touch the light bulb with bare hands.

•ReplacingLEDlamps(Fig.6.2):

If the appliance version is with LED lamps, the intervention of

a specialised technician is necessary to replace them.

•ComandsSlider (Fig.7)the key symbols are explained

below:

A = Light switch

A1 = O key

A2 = On key

B = Gemma warning light key

C = Speed control

C1 = O key

C2 = FIRST SPEED key

C3 = SECOND SPEED key

C4 = THIRD SPEED key.

•Commands:

-Luminous(Fig.8.1)

-Electronicthe(Fig.8.2) key symbols are explained below:

A = LIGHT

B = OFF

C = SPEED I

D = SPEED II

E = SPEED III

F = AUTOMATIC STOP TIMER - 15 minutes (*)

If your appliance does not have the INTENSIVE speed function,

press key E for two seconds and it will be activated for 10

minutes after which it will return to the previously set speed.

When the function is active the LED ashes. To interrupt it

Korting KHI9751X [20/60] Use and maintenance
