M-Powered Basics Guide
8
Recording a Pro Tools Session
Before you record with Pro Tools M-Powered,
you first create a Pro Tools session, then prepare
an audio track for recording.
To create a Pro Tools session:
1
Verify the connections between your M-Audio
interface and your instrument or microphone.
2
Launch Pro Tools.
3
Choose File > New Session.
4
In the New Session dialog, set the session pa-
rameters as needed, or leave them at their de-
fault settings. (For details on New Session
settings, see the
Pro Tools M-Powered Getting
Started Guide
.)
5
Choose where you want to save your session.
6
Type a name for your session.
7
Click Save.
To prepare an audio track for recording:
1
Choose Track > New.
2
Specify 1 Mono Audio Track in Samples, if
your source is mono, or 1 Stereo Audio Track in
Samples, if your source is stereo.
3
Click Create.
4
Make sure the Mix window is open by choos-
ing Window > Mix.
5
In the Mix window, click the Audio Input Path
selector on the new track.
New Session dialog
Creating a new Stereo audio track
A mono instrument uses one input on an
M-Audio interface, and a stereo instrument
uses two. Creating a stereo track in
Pro Tools will not make a mono instrument
into a stereo instrument. If a mono instru-
ment is recorded on a stereo track, one of the
sides of the stereo track will show no signal.
Choosing an input in the Mix window
Input Path selector
