Recording a Pro Tools Session
9
6
From the pop-up menu, select the interface in-
put you want to record. For example, select
Mic/Line 1 if your audio source is plugged into
the first input of your M-Audio interface.
7
Play the instrument or sound source at the
volume you will record.
8
Use the Signal Gain controls on your M-Audio
interface (if any) to maximize the signal going
into Pro Tools while avoiding clipping.
To record an audio track:
1
Click the Track Record Enable button.
2
Choose Window > Transport to display the
Transport window. Click Return to Zero to go to
the beginning of the session.
3
Click Record Enable in the Transport window
to arm Pro Tools for recording. The Record but-
ton flashes red to indicate that Pro Tools is ready
to record.
4
When you are ready to start recording, click
Play or press the Spacebar.
5
Record your performance.
6
Click Stop in the Transport window or press
the Spacebar when you are finished recording.
To play back a recorded track:
1
If the track’s Record Enable button is lit, click
on it to take it out of Record mode.
2
Click Play in the Transport window or press
the Spacebar to start playback.
3
Click Stop in the Transport window or press
the Spacebar to stop playback.
Routing an input to a mono track
Clipping occurs when you feed a signal to
an audio device that is louder than the
circuitry can accept. To avoid clipping,
adjust the Signal Gain control (if any). If
the M-Audio interface has front panel
Clip LEDS, adjust the gain to a level
where the Peak LEDs do not light.
Record enabling a track in the Mix window
Transport window
Fast Forward
Record Enable
Go to EndPlay
Stop
Rewind
Return to Zero
Online
