Introduction
1
Introduction
Welcome to the
M-Powered Basics Guide
. This
guide is designed to give new users specific
methods for accomplishing common tasks with
Digidesign-qualified M-Audio interfaces and
Pro Tools M-Powered software.
Once you are familiar with basic M-Powered op-
eration, we recommend that you read the
“Working With Pro Tools” tutorial in the
Pro Tools M-Powered Getting Started Guide
. For the
most complete information on using Pro Tools,
see the
Pro Tools Reference Guide
.
Online Resources
Many resources for learning to use Pro Tools are
also available online at the Digidesign Web site
(www.digidesign.com), including the following:
DiSK (Digidesign Sound Knowledge)
Instruc-
tional material about how to use Pro Tools, in-
cluding DiSK Flix movies that show how to do a
number of popular tasks using Pro Tools.
DigiZine
A magazine for and about Pro Tools us-
ers, providing all the latest product news, user
stories, and many tips and ideas.
M-Powered Basics Requirements
Before proceeding, make sure you have:
• Connected the Digidesign-qualified M-Audio
interface to your computer, as described in
your M-Audio documentation.
– and –
• Installed Pro Tools M-Powered software and
the pre-authorized iLok, as described in the
appropriate Windows or Macintosh installa-
tion chapter of the
Pro Tools M-Powered Getting
Started Guide.
