Nissan Note [14/14] Rear seat
![Nissan Note [14/14] Rear seat](/views2/1789826/page14/bge.png)
SE-14
REAR SEAT
1. Headrest 2. Seatback reclining cable RH 3. Reclining cable clip
4. Seatback reclining lever RH 5. Seatback frame RH 6. Headrest holder
7. Seatback reclining lever LH 8. Seat belt retractor centre 9. Rope hook
10. Seatback frame RH 11. Seatback frame LH 12. Seatback reclining cable LH
13. Seatback trim and pad RH 14. Armrest carpet 15. Armrest
16. Bolt 17. Bush 18. Armrest cap RH
19. Armrest cap LH 20. Seatback trim and pad LH 21. Seat rail cover RH
22. Seat rail cover LH 23. Carpet finisher 24. Seat belt buckle RH
25. Release bracket 26. Reclining device RH 27. Seat belt buckle centre
28. Slide seat handle 29. Release cross tube 30. Seat belt buckle LH
31. Reclining device LH 32. Hinge cover RH outer 33. Hinge cover RH inner
34. Reclining device cover RH 35. Reclining device cover LH 36. Hinge cover LH inner
37. Hinge cover LH outer 38. Cushion bracket RH 39. Pin
40. Rail assembly RH 41. Strap 42. Cushion bracket LH
43. Rail assembly LH 44. Seat cushion trim and pad 45. Cross bar
46. Leg cover RH 47. Slide seat lever 48. Leg cover LH
49. Seat cushion frame
