TROUBLE DIAGNOSIS
SRS-21
C
D
E
F
G
I
J
K
L
M
A
B
SRS
CONSULT-II DIAGNOSTIC CODE CHART (“SELF-DIAG [CURRENT]”)
Diagnostic item Explanation
Repair order
“Recheck SRS at each replacement”
NO DTC IS
DETECTED.
When malfunction is
indicated by the “AIR
BAG” warning lamp in
User mode.
● Low battery voltage (Less than 9V) ● Go to SRS-24, "DIAGNOSTIC PRO-
CEDURE 3" after charging the battery.
● Self-diagnostic result “SELF-DIAG
[PAST]” (previously stored in the
memory) might not be erased after
repair.
● Intermittent malfunction has been
detected in the past.
● Go to SRS-26, "DIAGNOSTIC PRO-
CEDURE 4 (CONTINUED FROM
DIAGNOSTIC PROCEDURE 2)" .
● Go to SRS-26, "DIAGNOSTIC PRO-
CEDURE 5" .
● No malfunction is detected. —
DRIVER AIRBAG
MODULE
[OPEN]
● Driver air bag module circuit is open (including the spiral
cable).
1. Visually check the wiring harness con-
nection.
2. Replace the harness if it has visible
damage.
3. Replace driver air bag module. (Before
disposal, it must be deployed.)
4. Replace the spiral cable.
5. Replace the diagnosis sensor unit.
6. Replace the related harness.
DRIVER AIRBAG
MODULE
[VB-SHORT]
● Driver air bag module circuit is shorted to a power supply cir-
cuit (including the spiral cable).
DRIVER AIRBAG
MODULE
[GND-SHORT]
● Driver air bag module circuit is shorted to ground (including
the spiral cable).
DRIVER AIRBAG
MODULE
[SHORT]
● Driver air bag module circuit is shorted between lines.
ASSIST A/B MODULE
[OPEN]
● Front passenger air bag module circuit is open. 1. Visually check the wiring harness con-
nection.
2. Replace the harness if it has visible
damage.
3. Replace front passenger air bag mod-
ule. (Before disposal, it must be
deployed.)
4. Replace the diagnosis sensor unit.
5. Replace the related harness.
ASSIST A/B MODULE
[VB-SHORT]
● Front passenger air bag module circuit is shorted to a power
supply circuit.
ASSIST A/B MODULE
[GND-SHORT]
● Front passenger air bag module circuit is shorted to ground.
ASSIST A/B MODULE
[SHORT]
● Front passenger air bag module circuit is shorted between
lines.
CRASH ZONE SEN
[UNIT FAIL]
CRASH ZONE SEN
[COMM FAIL]
CRASH ZONE SEN
[UNMATCH]
● Crash zone sensor 1. Visually check the wiring harness con-
nection.
2. Replace the harness if it has visible
damage.
3. Replace the crash zone sensor.
4. Replace the diagnosis sensor unit.
5. Replace the related harness.
SIDE MODULE LH
[OPEN]
● Front LH side air bag module circuit is open. 1. Visually check the wiring harness con-
nection.
2. Replace the harness if it has visible
damage.
3. Replace front LH setback assembly
(front LH side air bag module).
(Before disposal, it must be deployed.)
4. Replace the diagnosis sensor unit.
5. Replace the related harness.
SIDE MODULE LH
[VB-SHORT]
● Front LH side air bag module circuit is shorted to a power
supply circuit.
SIDE MODULE LH
[GND-SHORT]
● Front LH side air bag module circuit is shorted to ground.
SIDE MODULE LH
[SHORT]
● Front LH side air bag module circuit is shorted between lines.
