RXD-M57MP
21
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C272 CE04LW1C470M ELECTRO 47UF 16WV
C291 CK73GB1H223K CHIP C 0.022UF K
C302 CE04LW1C221M ELECTRO 220UF 16WV
C303-306 CK73GB1C105K CHIP C 1.0UF K
C309-312 CK73GB1C105K CHIP C 1.0UF K
C313,314 CC73GCH1H470J CHIP C 47PF J
C315,316 CK73GB1C105K CHIP C 1.0UF K
C317-320 C90-5820-08 CHIP C 0.47UF K
C321,322 CE04LW1HR33M ELECTRO 0.33UF 50WV
C323,324 CK73GB1H102K CHIP C 1000PF K
C325 CE04LW1C221M ELECTRO 220UF 16WV
C326 CK73GB1H104K CHIP C 0.10UF K
C327,328 CE04LW1C221M ELECTRO 220UF 16WV
C330 CE04LW1C470M ELECTRO 47UF 16WV
C331 CE04LW1C221M ELECTRO 220UF 16WV
C332 CE04LW1C100M ELECTRO 10UF 16WV
C339 CK73GB1C105K CHIP C 1.0UF K
C340 CE04LW1E222M ELECTRO 2200UF 25WV
C363,364 CK73GB1H102K CHIP C 1000PF K
C403 CK73GB1H221K CHIP C 220PF K E
C404 CK73GB1H221K CHIP C 220PF K
C405,406 CK73GB1H471K CHIP C 470PF K E
C410,411 CK73GB1C105K CHIP C 1.0UF K
C412,413 CC73GCH1H101J CHIP C 100PF J
C414 CK73GB1H221K CHIP C 220PF K
C415,416 CE04LW1H101M ELECTRO 100UF 50WV
C417 CC73GCH1H030C CHIP C 3.0PF C
C418 CE04LW1V222M ELECTRO 2200UF 35WV
C419 CK73GB1H221K CHIP C 220PF K
C420 CE04LW1H101M ELECTRO 100UF 50WV
C421 CC73GCH1H030C CHIP C 3.0PF C
C428 CE04LW1H101M ELECTRO 100UF 50WV
C429 C91-1681-08 FILM 0.1UF K
C435 CK73GB1C105K CHIP C 1.0UF K
C437 CK73GB1C105K CHIP C 1.0UF K
C440 CE04LW1H2R2M ELECTRO 2.2UF 50WV
C441 CE04LW1C101M ELECTRO 100UF 16WV
C442 CK73GB1C105K CHIP C 1.0UF K
C444 CE04LW1C101M ELECTRO 100UF 16WV
C445 CE04LW1V222M ELECTRO 2200UF 35WV
C446 CE04LW1C221M ELECTRO 220UF 16WV
C447 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C448 CK73GB1C105K CHIP C 1.0UF K
C449,450 CK73GB1H102K CHIP C 1000PF K
C451 CK73GB1H103K CHIP C 0.010UF K
C453 CK73GB1H102K CHIP C 1000PF K
C455 CK73GB1H223K CHIP C 0.022UF K
C457 CK73GB1C105K CHIP C 1.0UF K
C460 CK73GB1C105K CHIP C 1.0UF K
C461 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C463 CE04LW1C101M ELECTRO 100UF 16WV
C465 C91-1681-08 FILM 0.1UF K
C477 CK73GB1H222K CHIP C 2200PF K
C479,480 CC73GCH1H101J CHIP C 100PF J
C601 CE04LW1C470M ELECTRO 47UF 16WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
4
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C143 CK73GB1H223K CHIP C 0.022UF K
C144 CE04LW1H010M ELECTRO 1.0UF 50WV
C145,146 CC73GCH1H300J CHIP C 30PF J
C147 CK73GB1H223K CHIP C 0.022UF K
C148 CE04LW1C101M ELECTRO 100UF 16WV
C149 CK73GB1H223K CHIP C 0.022UF K
C150 CK45FB1H102K CERAMIC 1000PF K
C151,152 CK73GB1H103K CHIP C 0.010UF K
C153,154 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C155 CK73GB1H103K CHIP C 0.010UF K
C161,162 CK73GB1H682K CHIP C 6800PF K
C163,164 CC73GCH1H101J CHIP C 100PF J
C165 CK73GB1H104K CHIP C 0.10UF K
C167 CK73GB1H223K CHIP C 0.022UF K
C169 CC73GCH1H101J CHIP C 100PF J
C170 CE04LW1C101M ELECTRO 100UF 16WV E
C171 CC73GCH1H470J CHIP C 47PF J E
C172 CC73GCH1H020C CHIP C 2.0PF C
C173 CC73GCH1H470J CHIP C 47PF J E
C174 CE04LW1C101M ELECTRO 100UF 16WV E
C175 ✻ C91-1687-08 CERAMIC 560PF J E
C176 CE04LW1H2R2M ELECTRO 2.2UF 50WV E
C177 CE04LW1C101M ELECTRO 100UF 16WV E
C178 CK73GB1H223K CHIP C 0.022UF K E
C188 CK73GB1H102K CHIP C 1000PF K
C201 CC73GCH1H470J CHIP C 47PF J
C202 CK73GB1H102K CHIP C 1000PF K
C203 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C204 CE04LW1C221M ELECTRO 220UF 16WV
C205,206 CK73GB1H102K CHIP C 1000PF K
C220,221 CK45FB1H151K CERAMIC 150PF K
C222 CC73GCH1H470J CHIP C 47PF J
C223 CK45FB1H102K CERAMIC 1000PF K
C224 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C235 CE04LW1C221M ELECTRO 220UF 16WV
C236 CK73GB1H223K CHIP C 0.022UF K
C238 CE04LW1C100M ELECTRO 10UF 16WV
C239 CK45FB1H102K CERAMIC 1000PF K
C240 ✻ C91-1688-08 MYLAR 0.018UF K
C241,242 ✻ C91-1689-08 MYLAR 0.001UF K
C243 CE04KW1C471M ELECTRO 470UF 16WV
C245 CK73GB1H223K CHIP C 0.022UF K
C250 CK73GB1H223K CHIP C 0.022UF K
C252 CK73GB1H223K CHIP C 0.022UF K
C255,256 CK73GB1H221K CHIP C 220PF K
C257,258 CE04LW1C101M ELECTRO 100UF 16WV
C259,260 CK73GB1H183K CHIP C 0.018UF K
C261,262 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C263 CE04LW1C330M ELECTRO 33UF 16WV
C264,265 CE04LW1C470M ELECTRO 47UF 16WV
C266 CK73GB1H221K CHIP C 220PF K
C267 CK73GB1H102K CHIP C 1000PF K
C268 CK73GB1H221K CHIP C 220PF K
C269 CK73GB1H102K CHIP C 1000PF K
C270,271 CE04LW1H4R7M ELECTRO 4.7UF 50WV
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
3
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
