RXD-M57MP
23
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R142 RK73GB1J561J CHIP R 560 J 1/16W
R143 RK73GB1J103J CHIP R 10K J 1/16W
R148,149 RK73GB1J103J CHIP R 10K J 1/16W
R150 RK73GB1J104J CHIP R 100K J 1/16W
R153,154 RK73GB1J103J CHIP R 10K J 1/16W
R157 RK73GB1J394J CHIP R 390K J 1/16W
R159 RK73GB1J272J CHIP R 2.7K J 1/16W
R160 RK73GB1J151J CHIP R 150 J 1/16W
R161,162 RK73GB1J512J CHIP R 5.1K J 1/16W
R165,166 RK73GB1J332J CHIP R 3.3K J 1/16W
R174 RK73GB1J472J CHIP R 4.7K J 1/16W
R179 RK73GB1J684J CHIP R 680K J 1/16W
R201 RK73GB1J183J CHIP R 18K J 1/16W
R202 RK73GB1J104J CHIP R 100K J 1/16W
R204,205 RK73GB1J680J CHIP R 68 J 1/16W
R206,207 RK73GB1J682J CHIP R 6.8K J 1/16W
R210 RK73GB1J000J CHIP R 0 J 1/16W
R211,212 CK73GB1H102K CHIP C 1000PF K
R213 RK73GB1J472J CHIP R 4.7K J 1/16W
R214 RK73GB1J104J CHIP R 100K J 1/16W
R215,216 RK73GB1J221J CHIP R 220 J 1/16W
R218,219 RK73GB1J124J CHIP R 120K J 1/16W
R226 RK73GB1J104J CHIP R 100K J 1/16W
R227 RK73GB1J103J CHIP R 10K J 1/16W
R228 RK73GB1J105J CHIP R 1.0M J 1/16W
R235 RK73GB1J102J CHIP R 1.0K J 1/16W
R236 RK73GB1J472J CHIP R 4.7K J 1/16W
R238 RK73GB1J681J CHIP R 680 J 1/16W
R243 RK73GB1J103J CHIP R 10K J 1/16W
R244 RK73GB1J104J CHIP R 100K J 1/16W
R245 RK73GB1J103J CHIP R 10K J 1/16W
R247 RK73GB1J103J CHIP R 10K J 1/16W
R250 RK73GB1J223J CHIP R 22K J 1/16W
R251 RK73GB1J104J CHIP R 100K J 1/16W
R253 RK73GB1J000J CHIP R 0 J 1/16W
R259 RK73GB1J223J CHIP R 22K J 1/16W
R261 RK73GB1J104J CHIP R 100K J 1/16W
R262 RK73GB1J103J CHIP R 10K J 1/16W
R264 RK73GB1J103J CHIP R 10K J 1/16W
R265 RK73GB1J223J CHIP R 22K J 1/16W
R266 RK73GB1J103J CHIP R 10K J 1/16W
R267 RK73GB1J104J CHIP R 100K J 1/16W
R301 RK73GB1J680J CHIP R 68 J 1/16W
R302 RK73GB1J471J CHIP R 470 J 1/16W
R303 RK73GB1J394J CHIP R 390K J 1/16W
R304 RK73GB1J561J CHIP R 560 J 1/16W
R307 RK73GB1J471J CHIP R 470 J 1/16W
R308 RK73GB1J394J CHIP R 390K J 1/16W
R310 RK73GB1J561J CHIP R 560 J 1/16W
R312 RK73GB1J472J CHIP R 4.7K J 1/16W
R314 RD14BB2E100J RD 10 J 1/4W
R315 RK73GB1J561J CHIP R 560 J 1/16W
R318 RK73GB1J220J CHIP R 22 J 1/16W
R319 RD14BB2H680J RD 68 J 1/2W
R333 RK73GB1J104J CHIP R 100K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
8
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
CF105 ✻ L79-1304-08 Ceramic Filter 09-50107-20J
CN601 ,2 ✻ L92-0821-08 Ferrite Core T108-04344-21
CN607 ✻ L92-0821-08 Ferrite Core T108-04344-21
CN700 ✻ L92-0812-08 Ferrite Core T108-04344-99
L102 ✻ E35-3714-08 10 mm IFT RED 108-01014-02
L103 ✻ L32-1062-08 AM ANT Coil OA108-86436-70
L104 ✻ L32-1066-08 7 mm FM DET 11408-73995-00
L105 ✻ L92-0814-08 Inductor 10 mH-L92-0814-08T
L108 ✻ L92-0815-08 Axial Lead Indu09-70102-02T E
L201,202 ✻ L33-1704-08 Choke Coil 47 m09-40474-00W
L203 ✻ L32-1067-08 Bias OSC Coil 708-07163-00
L301 ✻ L92-0816-08 Axial Inductor 09-70222-03T
L403,404 ✻ L33-1690-08 Choke Coil 8 mH09-40080-00W
L405,406 ✻ L92-0822-08 Ferrite Coil 4T08-04344-40
L407 ✻ L33-1690-08 Choke Coil 8 mH (WLF-800081)
L408 ✻ L92-0822-08 Ferrite Coil 4T(3.5X3X1.3)
L409 ✻ L33-1690-08 Choke Coil 8 mH (WLF-800081)
L412,413 ✻ L92-0823-08 TWP9-3R9M 3.9 m09-00390-05
L602 ✻ L92-0824-08 Axial Lead Indu09-70221-00C
L701,702 ✻ L92-0825-08 Lead Free Axial09-70471-80
L703,704 ✻ L92-0814-08 Inductor 10 mH-L92-0814-08T
L706-709 ✻ L92-0825-08 Lead Free Axial09-70471-80
L710 ✻ L33-1689-08 Choke Coil W/Ma09-01000-01
L901 ✻ L33-1703-08 Lead Free Commo09-00400-00O
T101 ✻ L30-0992-08 AM IFT A010-86508-05200-00
TR901 ✻ L07-3304-08 HM337 X’Former 15-00337-05 EM
TR901 ✻ L07-3305-08 HM337 X’Former 15-00337-07 X
X101 ✻ L77-2436-08 Crystal 7.2 MHz04-07200-05D
X102 ✻ L77-2435-08 Crystal 4.332 M04-04332-06 E
X601 ✻ L77-2436-08 Crystal 7.2 MHz04-07200-05D
X602 ✻ L77-2438-08 Crystal 3 X 8 m04-32768-09
X701 ✻ L77-2437-08 Crystal 16.934404-16934-49
R1-5 RK73GB1J000J CHIP R 0 J 1/16W
R102 RK73GB1J124J CHIP R 120K J 1/16W
R106 RK73GB1J101J CHIP R 100 J 1/16W
R107 RK73GB1J103J CHIP R 10K J 1/16W
R108 RK73GB1J223J CHIP R 22K J 1/16W
R110,111 RK73GB1J183J CHIP R 18K J 1/16W
R113 RK73GB1J102J CHIP R 1.0K J 1/16W
R114 RK73GB1J223J CHIP R 22K J 1/16W
R115 RK73GB1J104J CHIP R 100K J 1/16W
R116 RK73GB1J104J CHIP R 100K J 1/16W E
R117 RK73GB1J102J CHIP R 1.0K J 1/16W
R118-120 RK73GB1J103J CHIP R 10K J 1/16W
R122 RK73GB1J104J CHIP R 100K J 1/16W
R123 RK73GB1J101J CHIP R 100 J 1/16W
R124 RK73GB1J223J CHIP R 22K J 1/16W
R125 RK73GB1J472J CHIP R 4.7K J 1/16W
R126 RK73GB1J103J CHIP R 10K J 1/16W
R129 RK73GB1J563J CHIP R 56K J 1/16W
R133 RK73GB1J473J CHIP R 47K J 1/16W
R134 RK73GB1J152J CHIP R 1.5K J 1/16W
R139 RK73GB1J102J CHIP R 1.0K J 1/16W
R140,141 RK73GB1J152J CHIP R 1.5K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
7
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
