RXD-M57MP
22
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C754 CE04LW1C470M ELECTRO 47UF 16WV
C755-757 CK73GB1H223K CHIP C 0.022UF K
C758-760 CK45FB1E223Z CERAMIC 0.022UF Z
C761,762 CK73GB1H223K CHIP C 0.022UF K
C763 CK73GB1H104K CHIP C 0.10UF K
C764 CK73GB1H334K CHIP C 0.33UF K
C765 C91-0745-05 CERAMIC 100PF K
C766,767 CK73GB1H223K CHIP C 0.022UF K
C768 CE04LW1C470M ELECTRO 47UF 16WV
C769 CC73GCH1H181J CHIP C 180PF J
C770 CE04LW1C101M ELECTRO 100UF 16WV
C771 CK45FB1H101K CERAMIC 100PF K
C772,773 CK73GB1H223K CHIP C 0.022UF K
C774 CK73GB1H104K CHIP C 0.10UF K
C775 CC73GCH1H020C CHIP C 2.0PF C
C776 CK73GB1H104K CHIP C 0.10UF K
C777 CE04LW1C470M ELECTRO 47UF 16WV
C778 CK73GB1H223K CHIP C 0.022UF K
C779,780 CE04LW1C101M ELECTRO 100UF 16WV
C781 CK73GB1H223K CHIP C 0.022UF K
C782 CE04LW1H2R2M ELECTRO 2.2UF 50WV
C783 CK73GB1H223K CHIP C 0.022UF K
C784,785 CK73GB1H103K CHIP C 0.010UF K
C786 CK73GB1H104K CHIP C 0.10UF K
C787 CE04LW1C470M ELECTRO 47UF 16WV
C788 CE04LW1C100M ELECTRO 10UF 16WV
C791 CE04LW1C470M ELECTRO 47UF 16WV
C792 CK73GB1H223K CHIP C 0.022UF K
C793 CE04LW1C221M ELECTRO 220UF 16WV
C795 CE04LW1C470M ELECTRO 47UF 16WV
C797,798 CE04LW1C470M ELECTRO 47UF 16WV
C909-917 CK45FB1E223Z CERAMIC 0.022UF Z
C918 CE04LW1C332M ELECTRO 3300UF 16WV
C919,920 CK45FB1E223Z CERAMIC 0.022UF Z
C921,922 C91-0757-05 CERAMIC 1000PF K
C923 C91-1686-08 CERAMIC 0.001UF 250VAC
C925 CE04LW1C101M ELECTRO 100UF 16WV
J68 CK45FB1H103K CERAMIC 0.010UF K
TC101 C05-0236-08 Trimmer 10 pF T05-08100-02
CN3 ✻ E70-0200-08 FM 75 ohm Ant.S12-00007-21
CN401 ✻ E70-1001-08 NSX-1 Speak Ter12-00006-02
CN403 ✻ L92-0812-08 Ferrite Core T108-04344-99
CN704 E40-8104-08 16 Pin FFC Sock20-80160-00I
JK400 E11-0981-08 3.5 MMJK W/2P2T12-21235-15Q
Prorect L ine ✻ L92-0820-08 Ferrite Core T108-04344-11
F901 ✻ F50-0261-08 Fuse T1.6AL 25033-57162-03W
F902,903 ✻ F50-0262-08 Fuse T3.15L 25033-57312-03W
F904 ✻ F50-0261-08 Fuse T1.6AL 25033-57162-03W
AC Cord ✻ L92-0807-08 Ferrite Core T208-04344-50
BP101 L79-1247-08 FM BP Filter BP09-80001-00T
CF101,102 ✻ L79-1304-08 Ceramic Filter 09-50107-20J
CF103 ✻ L79-1303-08 Ceramic Filter 09-50450-09
CF104 ✻ L79-1302-08 Ceramic Display 09-50107-07J
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
6
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
C602 CE04LW1A221M ELECTRO 220UF 10WV
C603 CE04LW1C470M ELECTRO 47UF 16WV
C605 CK73GB1H104K CHIP C 0.10UF K
C606-609 CC73GCH1H240J CHIP C 24PF J
C610 CE04LW1A221M ELECTRO 220UF 10WV
C613 CE04LW1A470M ELECTRO 47UF 10WV
C614 CK73GB1H223K CHIP C 0.022UF K
C618 CE04LW1A101M ELECTRO 100UF 10WV
C619 CK73GB1H223K CHIP C 0.022UF K
C622 CE04LW1C100M ELECTRO 10UF 16WV
C628 CK73GB1H223K CHIP C 0.022UF K
C630 CK73GB1H102K CHIP C 1000PF K
C648 CK73GB1H223K CHIP C 0.022UF K
C660 CE04LW1C100M ELECTRO 10UF 16WV
C666 CK73GB1H102K CHIP C 1000PF K
C668 CK73GB1H102K CHIP C 1000PF K
C700 CE04LW1C101M ELECTRO 100UF 16WV
C701 CK73GB1H223K CHIP C 0.022UF K
C703 CK45FB1E223Z CERAMIC 0.022UF Z
C704 CE04LW1C221M ELECTRO 220UF 16WV
C705 CE04LW1C470M ELECTRO 47UF 16WV
C707 CE04LW1C221M ELECTRO 220UF 16WV
C708,709 CE04LW1C470M ELECTRO 47UF 16WV
C710 CE04LW1C220M ELECTRO 22UF 16WV
C711 CE04LW1C470M ELECTRO 47UF 16WV
C712 CK73GB1H223K CHIP C 0.022UF K
C713 CE04LW1C470M ELECTRO 47UF 16WV
C714 CK73GB1C105K CHIP C 1.0UF K
C715 CE04LW1C470M ELECTRO 47UF 16WV
C716 CK73GB1H223K CHIP C 0.022UF K
C717,718 CC73GCH1H300J CHIP C 30PF J
C719,720 CE04LW1C470M ELECTRO 47UF 16WV
C721 CK73GB1H223K CHIP C 0.022UF K
C722,723 CE04LW1C470M ELECTRO 47UF 16WV
C724 CE04LW1C471M ELECTRO 470UF 16WV
C725 C90-5820-08 CHIP C 0.47UF K
C726-728 CK73GB1H104K CHIP C 0.10UF K
C729 C90-5820-08 CHIP C 0.47UF K
C730 CK73GB1H104K CHIP C 0.10UF K
C731,732 CK73GB1H473K CHIP C 0.047UF K
C733,734 CE04LW1H4R7M ELECTRO 4.7UF 50WV
C735 CE04LW1C470M ELECTRO 47UF 16WV
C736 CK73GB1H153K CHIP C 0.015UF K
C737 CK73GB1H103K CHIP C 0.010UF K
C738 CC73GCH1H470J CHIP C 47PF J
C739 CK73GB1H272K CHIP C 2700PF K
C740 CE04LW1C470M ELECTRO 47UF 16WV
C741 CK73GB1H473K CHIP C 0.047UF K
C742,743 CC73GCH1H471J CHIP C 470PF J
C744 CK73GB1H473K CHIP C 0.047UF K
C745 CK73GB1H104K CHIP C 0.10UF K
C746 CK73GB1H472K CHIP C 4700PF K
C747 CE04LW1C470M ELECTRO 47UF 16WV
C748,749 CK73GB1H473K CHIP C 0.047UF K
C750,751 CK73GB1H152K CHIP C 1500PF K
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
5
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
