RXD-M57MP
24
PARTS LIST
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R517 RK73GB1J182J CHIP R 1.8K J 1/16W
R518 RK73GB1J222J CHIP R 2.2K J 1/16W
R519 RK73GB1J392J CHIP R 3.9K J 1/16W
R520 RK73GB1J562J CHIP R 5.6K J 1/16W
R521 RK73GB1J822J CHIP R 8.2K J 1/16W
R522 RK73GB1J153J CHIP R 15K J 1/16W
R523 RK73GB1J273J CHIP R 27K J 1/16W
R524 RK73GB1J272J CHIP R 2.7K J 1/16W
R601 RK73GB1J473J CHIP R 47K J 1/16W
R602 RK73GB1J103J CHIP R 10K J 1/16W
R603,604 RK73GB1J102J CHIP R 1.0K J 1/16W
R611 RK73GB1J000J CHIP R 0 J 1/16W
R616 RK73GB1J103J CHIP R 10K J 1/16W
R618 RK73GB1J103J CHIP R 10K J 1/16W
R620 RK73GB1J103J CHIP R 10K J 1/16W
R621 RK73GB1J220J CHIP R 22 J 1/16W
R623 RK73GB1J473J CHIP R 47K J 1/16W
R628 RK73GB1J470J CHIP R 47 J 1/16W
R631 RK73GB1J102J CHIP R 1.0K J 1/16W
R634,635 RK73GB1J103J CHIP R 10K J 1/16W
R638 RK73GB1J100J CHIP R 10 J 1/16W
R639 RK73GB1J332J CHIP R 3.3K J 1/16W
R642 RK73GB1J103J CHIP R 10K J 1/16W
R643,644 RK73GB1J682J CHIP R 6.8K J 1/16W
R645 RK73GB1J103J CHIP R 10K J 1/16W
R646 RK73GB1J154J CHIP R 150K J 1/16W
R647-650 RK73GB1J103J CHIP R 10K J 1/16W
R653,654 RK73GB1J270J CHIP R 27 J 1/16W S
R653,654 RK73GB1J680J CHIP R 68 J 1/16W H
R655 RK73GB1J102J CHIP R 1.0K J 1/16W
R656 RK73GB1J104J CHIP R 100K J 1/16W
R657 RK73GB1J202J CHIP R 2.0K J 1/16W
R658 RK73GB1J104J CHIP R 100K J 1/16W
R661 RK73GB1J103J CHIP R 10K J 1/16W
R700 RS14DB2H6R8J FL-PROOF RS 6.8 J 1/2W
R701-704 RK73GB1J221J CHIP R 220 J 1/16W
R705,706 RK73GB1J302J CHIP R 3.0K J 1/16W
R709-715 RK73GB1J103J CHIP R 10K J 1/16W
R717 RK73GB1J101J CHIP R 100 J 1/16W
R719 RK73GB1J271J CHIP R 270 J 1/16W
R720 RK73GB1J511J CHIP R 510 J 1/16W
R721-725 RK73GB1J332J CHIP R 3.3K J 1/16W
R729 RK73GB1J224J CHIP R 220K J 1/16W
R730 RK73GB1J683J CHIP R 68K J 1/16W
R731 RK73GB1J103J CHIP R 10K J 1/16W
R732 RK73GB1J332J CHIP R 3.3K J 1/16W
R733 RK73GB1J473J CHIP R 47K J 1/16W
R734 RK73GB1J511J CHIP R 510 J 1/16W
R735-737 RK73GB1J103J CHIP R 10K J 1/16W
R738 RK73GB1J102J CHIP R 1.0K J 1/16W
R739 RK73GB1J103J CHIP R 10K J 1/16W
R741 RK73GB1J103J CHIP R 10K J 1/16W
R742 RK73GB1J101J CHIP R 100 J 1/16W
R749 RK73GB1J103J CHIP R 10K J 1/16W
R751 RK73GB1J103J CHIP R 10K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
0
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
Ref. No
Add-
ress
New
Parts
Parts No.
Description
Desti-
nation
Re-
marks
R334 RK73GB1J681J CHIP R 680 J 1/16W
R335 RK73GB1J104J CHIP R 100K J 1/16W
R351,352 RK73GB1J472J CHIP R 4.7K J 1/16W
R403 RK73GB1J000J CHIP R 0 J 1/16W
R404,405 RK73GB1J103J CHIP R 10K J 1/16W
R414,415 RK73GB1J333J CHIP R 33K J 1/16W
R417 RK73GB1J000J CHIP R 0 J 1/16W
R418,419 RK73GB1J563J CHIP R 56K J 1/16W
R420 RK73GB1J152J CHIP R 1.5K J 1/16W
R423,424 ✻ R92-4670-08 FL-PROOF RS 0.27 J 2W
R425 RK73GB1J103J CHIP R 10K J 1/16W
R427 RK73GB1J152J CHIP R 1.5K J 1/16W
R429 RK73GB1J102J CHIP R 1.0K J 1/16W
R432,433 RK73GB1J563J CHIP R 56K J 1/16W
R434 RK73GB1J102J CHIP R 1.0K J 1/16W
R440 RK73GB1J683J CHIP R 68K J 1/16W
R448 RK73GB1J104J CHIP R 100K J 1/16W
R449,450 ✻ R92-4670-08 FL-PROOF RS 0.27 J 2W
R452 RK73GB1J223J CHIP R 22K J 1/16W
R453 RK73GB1J102J CHIP R 1.0K J 1/16W
R454 RK73GB1J000J CHIP R 0 J 1/16W
R455 RK73GB1J103J CHIP R 10K J 1/16W
R457 RK73GB1J103J CHIP R 10K J 1/16W
R458 RK73GB1J393J CHIP R 39K J 1/16W
R459 RK73GB1J103J CHIP R 10K J 1/16W
R461-464 RD14BB2H4R7J RD 4.7 J 1/2W
R465 RK73GB1J472J CHIP R 4.7K J 1/16W
R467 RK73GB1J000J CHIP R 0 J 1/16W
R469 RK73GB1J472J CHIP R 4.7K J 1/16W
R478 RK73GB1J103J CHIP R 10K J 1/16W
R479 RK73GB1J473J CHIP R 47K J 1/16W
R480 RK73GB1J332J CHIP R 3.3K J 1/16W
R482,483 RK73GB1J103J CHIP R 10K J 1/16W
R484 RK73GB1J472J CHIP R 4.7K J 1/16W
R485 RK73GB1J103J CHIP R 10K J 1/16W
R491 RK73GB1J104J CHIP R 100K J 1/16W
R492 RK73GB1J000J CHIP R 0 J 1/16W
R495 RK73GB1J104J CHIP R 100K J 1/16W
R500 RK73GB1J750J CHIP R 75 J 1/16W
R501 RK73GB1J471J CHIP R 470 J 1/16W
R502 RK73GB1J681J CHIP R 680 J 1/16W
R503 RK73GB1J821J CHIP R 820 J 1/16W
R504 RK73GB1J102J CHIP R 1.0K J 1/16W
R505 RK73GB1J272J CHIP R 2.7K J 1/16W
R506 RK73GB1J182J CHIP R 1.8K J 1/16W
R507 RK73GB1J223J CHIP R 22K J 1/16W
R508 RK73GB1J561J CHIP R 560 J 1/16W
R509 RK73GB1J390J CHIP R 39 J 1/16W
R510 RK73GB1J153J CHIP R 15K J 1/16W
R511 RK73GB1J273J CHIP R 27K J 1/16W
R512 RK73GB1J750J CHIP R 75 J 1/16W
R513 RK73GB1J471J CHIP R 470 J 1/16W
R514 RK73GB1J152J CHIP R 1.5K J 1/16W
R515 RK73GB1J102J CHIP R 1.0K J 1/16W
R516 RK73GB1J272J CHIP R 2.7K J 1/16W
✽ New Parts
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
9
L : Scandinavia K : USA P : Canada R : Mexico C : China I : Malaysia
Y : PX(Far East,Hawaii) T : England E : Europe G : Germany V : China(Shanghai)
Y : AAFES(Europe) X : Australia Q : Russia H : Korea M : Other Areas indicates safety critical components .
