GA-8VT880P Combo Motherboard - 38 -
English
2-4 Power Management Setup
ACPI Suspend Type
S1(POS) Set ACPI suspend type to S1/POS(Power On Suspend). (Default value)
S3(STR) Set ACPI suspend type to S3/STR(Suspend To RAM).
USB Device Wake-Up From S3
Disabled Disable USB Device Wake-Up from S3. (Default value)
Enabled Enable USB Device Wake-Up from S3.
Power LED in S1 state
Blinking In standby mode(S1), power LED will blink. (Default value)
OFF In standby mode(S1), power LED will turn off.
Soft-Off by PWRBTN
Instant-Off Press power button then Power off instantly. (Default value)
Delay 4 Sec. Press power button 4 sec. to Power off. Enter suspend if button is pressed
less than 4 sec.
AC BACK Function
Memory When AC-power back to the system, the system will be back to the last state
before AC-power is lost.
Soft-Off When AC-power back to the system, the system will be in "Off" state.
(Default value)
Full-On When AC-power back to the system, the system always in "On" state.
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Power Management Setup
ACPI Suspend Type [S1(POS)]
x USB Device Wake-Up From S3 Disabled
Power LED in S1 state [Blinking]
Soft-Off by PWRBTN [Instant-Off]
AC BACK Function [Soft-Off]
Keyboard Power On [Disabled]
Mouse Power On [Disabled]
PME Event Wake Up [Enabled]
Modem Ring Resume [Enabled]
Resume by Alarm [Disabled]
x Date (of Month) Alarm Everday
x Time (hh:mm:ss) Alarm 0 : 0 : 0
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
[S1]
Set suspend type to
Power On Suspend under
ACPI OS
[S3]
Set suspend type to
Suspend to RAM under
ACPI OS
