GA-8VT880P Combo Motherboard - 42 -
English
2-7 MB Intelligent Tweaker(M.I.T.)
Incorrect using these features may cause your system broken. For power end-user use only.
CPU Clock Ratio
This setup option will automatically assign by CPU detection.
The option will display "Locked" and read only if the CPU ratio is not changeable.
CPU Host Clock Control
Please note that if your system is overclocked and cannot restart, please wait 20secs.
for automatic system restart or clear the CMOS setup data and perform a safe restart.
Disabled Disable CPU Host Clock Control. (Default value)
Enabled Enable CPU Host Clock Control.
CPU Clock
200MHz ~ 600MHz Set CPU Host Clock from 200MHz to 600MHz.
Incorrectly using this function may damage your system. For power users only.
C.I.A. Function
C.I.A. (CPU Intelligent Acelerator) is designed to detect CPU loading during software program
executing, and automatically adjust CPU computing power to maximize system performance.
Disabled Disable this function. (Default value)
Enabled Enable this function.
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Frequency/Voltage Control
CPU Clock Ratio [16X]
CPU Host Clock Control [Disabled]
x CPU Clock 200MHz
C.I.A. Function [Disabled]
x C.I.A. Frequency (Mhz) Cruise
x Fixed AGP/PCI Frequency Disabled
AGP/PCI Frequency 66/33
DRAM Clock [Auto]
CPU Voltage Control [Normal]
Normal CPU Vcore 1.3875V
AGP Voltage Control [Normal]
DDR Voltage Control [Normal]
KLJI: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
Voltage Set to Voltage when you use a CPU fan with a 3-pin fan power cable.
PWM Set to PWM when you use a CPU fan with a 4-pin fan power cable.
Note: In fact, the Voltage option can be used for CPU fans with 3-pin or 4-pin power cables.
However, some 4-pin CPU fan power cables are not designed following Intel 4-Wire fans PWM
control specifications. With such CPU fans, selecting PWM will not effectively reduce the fan speed.
