1.1 General warnings
After unpacking, make sure that all the components
are present. If not, contact your installer of your DAIKIN
affiliate office.
DAIKIN appliances must be installed by an authorised
installer who, on completion of the work, will release a
declaration of conformity to the client in respect of the
laws in force and the indications given by DAIKIN in the
instructions leaflet supplied together with the appliance.
These appliances have been designed both for
conditioning and/or heating environments and must
be destined for this use only and compatibly with their
performance characteristics.
DAIKIN EUROPE N.V. accepts no responsibility, either
contractual or extra-contractual, for any damage caused
to persons, animals of property as a result of incorrect
installation, adjustment or maintenance or improper use.
In case of water leaks, turn the master switch of the
system to "OFF" and close the water taps.
As soon as possible, call the DAIKIN technical service
department or else professionally qualified personnel
and do not intervene personally on the appliance.
If the appliance is not used for a long period of time,
the following operations should be performed:
- Turn the master switch of the system to "OFF"
- Close the water taps
- If there is the risk of freezing, make sure that anti-freeze
has been added to the system otherwise empty the
system.
If the room temperature is too low or too high it is
damaging for the health and is also a useless waste of
energy.
Avoid prolonged contact with the direct air flow.
Do not leave the room closed for long periods.
Periodically open the windows to ensure a correct
change of air.
This instruction leaflet is an integral part of the
appliance and consequently must be kept carefully
and must ALWAYS accompany the appliance, even
when it is passed to a new owner or user or transferred
onto another system. If it is lost or damaged, please
contact the local DAIKIN technical service centre.
All repair or maintenance interventions must be
performed by the technical service department or by
professionally qualified personnel as foreseen in this
booklet. Do not modify or intervene on the appliance
as this could create dangerous situations and the
manufacturer will not be responsible for any damage
caused.
Danger from burns - take care when touching
GENERAL
