To adjust/overrule the leaving water temperature (NOT linked to room temperature setpoint)

INFORMATION

To see if the leaving water temperature setpoint is linked to the room temperature

setpoint, see "4.4.3Determining which temperature control you are using"[416].

To adjust the leaving water temperature (main)

1 Go to the main leaving water temperature home page (LWT main).

2 Press or to adjust. Example:

35°C 37°C

INFORMATION

In case of weather dependency, an offset value can be modified.

To adjust the leaving water temperature (additional)

1 Go to the additional leaving water temperature home page (LWT add).

2 Press or to adjust. Example:

45°C 47°C

INFORMATION

In case of weather dependency, an offset value can be modified.

To adjust/overrule the leaving water temperature (linked to room temperature setpoint)

INFORMATION

To see if the leaving water temperature setpoint is linked to the room temperature

setpoint, see "4.4.3Determining which temperature control you are using"[416].

To set leaving water temperature preset values (main)

INFORMATION

You cannot adjust/overrule the leaving water temperature (main) for room

thermostat control with linked leaving water temperatures. However if necessary,

you can adjust the desired leaving water temperature (main) by adjusting preset

values.

INFORMATION

Adjusting the leaving water temperature is permanent unless the leaving water

temperature is according to a schedule. In that case the overruling is valid until the

next scheduled action.

1 Go to [7.4.2]: > User settings > Preset values > LWT main.

2 Set the Preset values according to following graph.

Example: Room thermostat comfort temperature will correspond with leaving

water comfort temperature.
