4 | Operation
User reference guide
35
EHYHBH05AF + EHYHBH/X05+08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355632-1E – 2020.10
Setting Value
Operation mode Heating
Heating 12°C
2 Activate the holiday mode.
▪ Go to [2.1]: > Holiday > Holiday.
▪ Select Yes and press .
Advantage:
▪ Before and after your holiday, your normal schedule will be used.
▪ During your holiday, you save energy and prevent your house from freezing.
Usage example: You come home during your holiday
If you are in the following situation:
▪ You configured and activated the holiday mode (Away).
▪ During your holiday, you come home for a few hours and want to use your
normal schedule.
Then you can do the following:
1 Deactivate the holiday mode.
2 When you go away again, activate the holiday mode again.
Advantage:
You do NOT have to change your schedule or holiday configuration.
4.6.4 Reading out information
To read out information
Prerequisite: You switched the permission level to Advanced end user.
1 Go to [6]: > Information.
Possible read-out information
In menu… You can read out…
[6.1] Sensor information Room, tank or DHW, outside, and
leaving water temperature. (If
applicable)
[6.2] Energy metering Produced energy, consumed electricity,
and consumed gas.
[6.3] Error handling Error history and contact/helpdesk
number.
[6.4] User permission level Current user permission level.
[6.5] Actuators Status/mode of each actuator.
Example: Domestic hot water pump
ON/OFF.
[6.6] Operation modes Current operation mode. Example:
Defrost/oil return mode.
[6.7] Running hours Running hours of the system.
[6.8] Version Version information about the system.
