4 | Operation
User reference guide
40
EHYHBH05AF + EHYHBH/X05+08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355632-1E – 2020.10
To select which schedule you currently want to use
1 Go to [5]: > Select schedules.
2 Select for which control you want to use a schedule. Example: [5.1] Room
temperature.
3 Select for which operation mode you want to use a schedule. Example: [5.1.1]
Heating .
4 Select a predefined or user‑defined schedule and press .
To program a schedule
1 Go to [7.3]: > User settings > Set schedules.
2 Open an empty, predefined or user‑defined schedule.
3 Change it.
4 Save it.
Guidelines when programming
07 :00
-- : -- --
Set heating schedule
Mon
Comfort
Select
Scroll
Delete line
Clear day schedule
Copy day
Save schedule
You can:
▪ Delete lines from the schedule
▪ Clear a day schedule
▪ Copy from one day to others
Usage example: You work in a 3-shift system
If you work in a 3-shift system, you can do the following:
1 Program 3 room temperature schedules and give them appropriate names.
Example: EarlyShift, DayShift and LateShift
2 Select the schedule that you currently want to use.
4.7.3 Schedules: Example
INFORMATION
The procedures to program other schedules are similar.
In this example:
▪ Room temperature schedule in heating mode
▪ Monday = Tuesday = Wednesday = Thursday = Friday
▪ Saturday = Sunday
To program the schedule
1 Go to [7.3.1.1]: > User settings > Set schedules > Room temp. >
Set heating schedule.
2 Select Empty and press .
3 Program the schedule for Monday. See below for more details.
