Daikin UATYQ30AFC2Y1 Инструкция по эксплуатации онлайн
Operation manual
Rooftop Packaged Unit
Models:
UATYQ20ABAY1
UATYQ25ABAY1
UATYQ30ABAY1
UATYQ45ABAY1
UATYQ50ABAY1
UATYQ55ABAY1
UATYQ65ABAY1
UATYQ75ABAY1
UATYQ90ABAY1
UATYQ110ABAY1
UATYQ115ABAY1
UATYQ20AFC2Y1
UATYQ25AFC2Y1
UATYQ30AFC2Y1
UATYQ45AFC2Y1
UATYQ50AFC2Y1
UATYQ55AFC2Y1
UATYQ65AFC2Y1
UATYQ75AFC2Y1
UATYQ90AFC2Y1
UATYQ110AFC2Y1
UATYQ115AFC2Y1
UATYQ20AFC3Y1
UATYQ25AFC3Y1
UATYQ30AFC3Y1
UATYQ45AFC3Y1
UATYQ50AFC3Y1
UATYQ55AFC3Y1
UATYQ65AFC3Y1
UATYQ75AFC3Y1
UATYQ90AFC3Y1
UATYQ110AFC3Y1
UATYQ115AFC3Y1
Operation manual
Rooftop Packaged Unit
English
Содержание
- Models 1
- Operation manual 1
- Rooftop packaged unit 1
- Rooftop packaged unit english 1
- Contents 3
- Operating guide 5 3
- User interface 4 3
- User interface 4
- Operating guide 5
- Software menu 5
- Main mask and menu 6
- Switching on off he unit from keyboard 7
- Temperatureandairflowsetpointadjust 7
- Clock menu and time slots setting 8
- Time slots programming examples 9
- Stopwashingfunction forcedfreecoolingatunitstart up 10
- Summer winter changeover from keyboard 11
- Input output visualization 12
- Change language and unit and software data visualization 14
- A automatic whenthealarmconditiondisappears thealarmisautomaticallyreset ac automaticcontrolled thealarmisautomaticallyresetforalimitednumberofattemptsinacertaintime after 15
- Above or by the supervisor reset variable for each alarm with manual reset the reset day and time are stored on the alarm history 15
- Alarms 15
- Eachalarmisidentifiedbyacode alxx andthealarmcauseisdescribedinthemask toresetanactivealarm press and hold for at least 2 seconds the alarm key if the alarm has been successfully reset the alarm mask disappears and if no other alarms are active the red alarm key is switched off an alarm can be reset only if the condition that has activated the alarm is not present anymore 15
- Inthe offunit column itisreportedifthealarmstopsthewholeunitornot 15
- M manualresetfromdisplayorfromsupervisor thealarmmustbemanuallyresetbydisplayasdescribed 15
- On alarm history menu last 150 alarms are stored when the memory is full and another alarm is activated the oldest alarm is overwritten in the following the full alarm list is reported with the main possible causes some troubleshooting hints the reset mode the action on the unit and on its components thealarmresetmodeisreportedonthe reset column 15
- That the reset becomes manual 15
- The manual reset of an alarm must be done only after checking the alarm cause and solving the problem that has activated the alarm the improper reset of an alarm can cause serious damages to the unit or to its components 15
- The mask displays the working hours of compressors 3 and 4 15
- When an alarm is triggered the red alarm key is on and the alarm digital output is activated by pressing the alarm key the last alarm is displayed the other active alarms can be scrolled with arrow keys thisisanexampleofanalarmmask 15
- Yes thealarmstopstheunit no thealarmdoesnotstoptheunit butonlytheconcerneddevices 15
- 1 maintenance alarms must be reset from masks ac ad ae of the maintenance menu and they cannot be reset by 21
- 2 the alarm is reset automatically but to clear the alarm visualization it is necessary to press and hold the alarm 21
- Key for at least 2 seconds 21
- Pressing the alarm key 21
- Cm_dkn_0001_rooftop_en_06 05 2019_rev02 24
- P522681 1 24
