Mounting and commissioning

FA EKSRDS2A - 06/2015 13

 During heating up, liquid must be able to escape via the

discharge line of the safety valve (no obstructions).

Install the safety valve in such a way that it cannot be

shut off.

Do not install shut-off valves, filters or similar equipment.

 Install the solar pump assembly in such a way that no ex-

ternal forces can act on the components after it has been

installed.

 Do not overheat the components by welding or soldering

work performed on the system. Install the solar pump as-

sembly after completion of such welding or soldering

work.

 Thoroughly flush the pipes prior to installing the solar

pump assembly. Impurities such as weld beads, hemp or

metal chips cause leaks of the safety valve and the check

valves.

 Verify that the nominal pressure of the solar pump as-

sembly corresponds to the specification value of the sys-

tem.

 Verify that the liquid in the system and the application ar-

ea of the solar pump assembly are compatible.

6.1 Mounting DAIKIN EKSRDS2A



Sealing surfaces have been check for cleanliness and

damage.



All pipe ends are perpendicular and have been deburred.

DAIKIN EKSRDS2A is delivered ready to be installed. Do not

disassemble parts.

1. Remove the upper insulation.

2. Hold DAIKIN EKSRDS2A with the lower insulation to the

wall (align with a level) and mark two positions.
