LRYEQ16A7Y1 + LCBKQ3AV1(E)
CONVENI-PACK
4P448940-1A – 2016.07
Operation manual
10
• Install an alarm if operational errors are likely to
degrade the commodities in storage.
The unit is provided with a terminal to output an
alarm signal.
If the system should malfunction and there is no
alarm, the operation of the unit will be interrupted
for a long time and damage to the commodities in
storage may result.
The installation of an alarm is recommended in
order to take appropriate measures promptly in
such cases.
For details, consult your dealer.
• Adjust the air outlet properly and avoid direct air
flow to room inhabitants.
• Adjust the room temperature properly for a com-
fortable environment. Avoid excessive heating or
cooling.
• Prevent direct sunlight from entering a room
during cooling operation by using curtains or
blinds.
• Ventilate often.
Extended use requires special attention to venti-
lation.
• Do not keep doors and windows opened. If the
doors and windows remain open, air will flow out
of your room causing a decrease in the cooling
or heating effect.
• Never place objects near the air inlet or the air
outlet of the unit. It may cause deterioration in
the effect or stop the operation.
• Turn off the main power supply switch to the unit
when the unit is not used for longer periods of
time. If the switch is on, it uses electricity. Before
restarting the unit, turn on the main power sup-
ply switch 6 hours before operation to ensure
smooth running. (Refer to the chapter “Mainte-
nance” in the indoor unit manual.)
• When the display shows “ ” (time to clean
the air filter), ask a qualified service person to
clean the filters. (Refer to the chapter “Mainte-
nance” in the indoor unit manual.)
• Keep the indoor unit and remote control at least
1 m away from televisions, radios, stereos, and
other similar equipment.
Failing to do so may cause static or distorted pic-
tures.
• Do not use other heating devices directly
beneath the indoor unit.
If you do, they might get deformed by the heat.
• It takes time for the room temperature to reach
the set temperature.
We recommend starting the operation in
advance using timer operation.
7. CARE AND CLEANING METHOD
Be sure to stop the operation of the unit with
the power switch and turn off the power (i.e.,
turn off the earth leakage breaker) before start-
ing the maintenance of the unit.
CAUTION
Do not touch the aluminium fin directly at
the time of cleaning.
Doing so may result in injury.
Do not wash the unit with water.
Doing so may result in electric shock or ignition.
Be sure to stop the operation of the unit and
turn off the power circuit breaker at the time of
cleaning, maintenance and inspection.
Otherwise, electric shock or injury may result.
Cleaning the outdoor unit
• Consult your local dealer.
Cleaning the indoor unit
• As the system is an all-in-one air-conditioner and
refrigerator, the fan may rotate in a heating mode
even if operation is stopped with the remote con-
troller.
Be sure to stop operation with the remote con-
troller and cut off the power breaker before
cleaning.
Refer to the operation manual attached to the
indoor unit for details.
Cleaning the showcase and the unit cooler
• Refer to the operation manual attached to the
showcase and the unit cooler for details.
Cleaning the drain pan (Optional accessory)
• Clean the drain pan so that it does not become
clogged and dusty.
• Turn off the power (i.e., turn off the earth leakage
breaker) if the unit is not used for a long time.
8. TROUBLESHOOTING
8-1 The following cases are not malfunc-
tions.
1. The unit does not operate.
• The air conditioner does not start immedi-
ately when restart the operation after stop
the operation or change operation mode
after set the operation mode.
If the operation lamp lights, the system is in
normal condition.
To prevent overloading of the compressor
motor, the air conditioner starts 5 minutes
after it is turned ON again in case it was
turned OFF just before.
4PEN448940-1A.book Page 10 Thursday, August 25, 2016 11:23 AM
