I

NSTALLATION

Remove the Transit Bolts

Before using this washing machine, transport bolts must be removed from the backside of this ma-

chine. Loosen all bolts with spanner and then remove them and keep the transport bolts properly for

future use/transport. Plug the holes with the transit bolts caps supplied.

- Avoid installation at locations with high humidity (e.g. outdoors), as metal parts would be suscepti-

ble to corrosion under such circumstances.

- Do not install in rooms where the temperature could drop below freezing. Do not expose the device

any weather.

- Do not place the device near volatile or combustible materials (e.g. gas, fuel, alcohol, paint, etc.).

- Only place on a steady and safe surface in order to reduce vibration and noise to a minimum.

- If the ground is evidently uneven (the maximum allowed tilt angle is 2°), it must be balanced, oth-

erwise the unit is wrong, vibrates or moves.

- If the floor is uneven, adjust the adjustable feet.

machine moves adjusts the feet. Loosen the locknuts with a

spanner.

Adjust the feet: to lower the dryer by turning right and to

ascend it by turning left. Tighten the locknut with the spanner

after insuring the device is leveled.

Once the position is fixed, you need to check the stability.

If not, repeat the action till it is leveled.

NOTE:

- The locknuts must be tightened after adjustment. Any looseness can cause vibration and noise.

There are two ways to place the end of drain hose:

- Hang into a sink or trough.

- Connect it to the branch drain pipe of the trough.

If the outlet spigot has not been used before, remove any blanking plug that may be in place.

Push the drain hose onto the spigot and secure with a clip if required, ensure a loop is formed in the

drain hose to prevent waste from the sink entering the washing machine.

If you need a drain hose extension, make sure to use a similar drain hose, but it must be no longer

than 4 meters; otherwise the washing effect could be reduced.
