![Haier HSU-12LEK03 [22/86] Indoor unit](/views2/1806606/page22/bg16.png)
Functions and control
Domestic Air Conditioner
Temperature control doesn’t work.
Temperature expiration control doesn’t work.
5.1.10 The memory function of power down
is available, and the auto recovery function of power on is optional. (In auto, heating, cooling, or
defrosting status, press the “sleeping” button 10 times within 5 seconds, and the auto recovery function of
power on can be set on/off. If the buzzer rings 4 times, the the auto recovery function of power on is available;
If the buzzer rings 2 times, the the auto recovery function of power on is unavailable.)
If there is no EEPROM, the unit is taken off the ‘off’ function of the memory function of power down. But
the memory function of power down can also be set on/off, and the data is the default value of chip.
5.1.11 Alarm from indoor fan motor:
2 minutes later after the indoor fan motor is charged, and the impulse from fan motor is not detected, hen
send alarm signals.
5.2 Value of Thermistor
5.2.1 Indoor unit
Room sensor
R25 =23Kȍ±3.5%ć
B25 /50 =4200K±3%ćć
Temp.(ć)
Max.(Kȍ) Normal(Kȍ) Min.(Kȍ)
Tolerance(ć)
-30 568.8372 501.0746 440.8435 -1.97 1.75
-29 530.9600 468.6491 413.1441 -1.95 1.74
-28 495.8488 438.5314 387.3645 -1.93 1.72
-27 463.2850 410.5433 363.3602 -1.91 1.71
-26 433.0683 384.5212 340.9980 -1.90 1.70
-25 405.0156 360.3153 320.1558 -1.88 1.69
-24 378.9588 337.7879 300.7211 -1.86 1.67
-23 354.7440 316.8126 282.5905 -1.84 1.66
-22 332.2300 297.2732 265.6686 -1.82 1.64
-21 311.2873 279.0627 249.8676 -1.80 1.63
-20 291.7969 262.0831 235.1067 -1.78 1.62
-19 273.6494 246.2437 221.3111 -1.76 1.60
-18 256.7445 231.4612 208.4122 -1.74 1.59
-17 240.9897 217.6590 196.3462 -1.72 1.57
-16 226.3000 204.7662 185.0545 -1.70 1.56
-15 212.5973 192.7176 174.4829 -1.68 1.54
-14 199.8093 181.4531 164.5813 -1.66 1.53
-13 187.8698 170.9169 155.3033 -1.64 1.51
-12 176.7176 161.0578 146.6059 -1.62 1.49
-11 166.2961 151.8284 138.4495 -1.60 1.48
-10 156.5532 143.1847 130.7973 -1.58 1.46
-9 147.4409 135.0863 123.6153 -1.56 1.44
HSU-07 09 12L HEK03
21
