Haier HSU-12LEK03 [25/86] Pipe sensor
![Haier HSU-12LEK03 [25/86] Pipe sensor](/views2/1806606/page25/bg19.png)
Functions and control
Domestic Air Conditioner
82 2.6050 2.3505 2.1182 -3.22 2.94
83 2.5203 2.2717 2.0451 -3.28 2.99
84 2.4388 2.1960 1.9749 -3.33 3.03
85 2.3602 2.1231 1.9075 -3.38 3.07
86 2.2846 2.0530 1.8426 -3.43 3.12
87 2.2118 1.9856 1.7803 -3.48 3.16
88 2.1416 1.9207 1.7204 -3.54 3.20
89 2.0740 1.8582 1.6628 -3.59 3.25
90 2.0089 1.7981 1.6074 -3.64 3.29
91 1.9461 1.7402 1.5541 -3.70 3.34
92 1.8856 1.6844 1.5028 -3.75 3.38
93 1.8272 1.6307 1.4535 -3.80 3.43
94 1.7709 1.5789 1.4060 -3.86 3.47
95 1.7166 1.5291 1.3603 -3.91 3.52
96 1.6643 1.4810 1.3163 -3.97 3.56
97 1.6138 1.4347 1.2739 -4.02 3.61
98 1.5650 1.3900 1.2331 -4.08 3.66
99 1.5180 1.3470 1.1937 -4.13 3.70
100 1.4726 1.3054 1.1559 -4.19 3.75
101 1.4287 1.2654 1.1194 -4.24 3.80
102 1.3864 1.2268 1.0842 -4.30 3.84
103 1.3455 1.1895 1.0503 -4.36 3.89
104 1.3060 1.1535 1.0176 -4.42 3.94
105 1.2679 1.1188 0.9860 -4.47 3.98
106 1.2310 1.0853 0.9556 -4.53 4.03
107 1.1954 1.0529 0.9263 -4.59 4.08
108 1.1610 1.0217 0.8980 -4.65 4.13
109 1.1277 0.9915 0.8707 -4.70 4.17
110 1.0955 0.9624 0.8443 -4.76 4.22
111 1.0644 0.9342 0.8189 -4.82 4.27
112 1.0344 0.9070 0.7943 -4.88 4.32
113 1.0053 0.8807 0.7706 -4.94 4.37
114 0.9771 0.8553 0.7478 -5.00 4.41
115 0.9499 0.8307 0.7256 -5.06 4.46
116 0.9235 0.8070 0.7043 -5.12 4.51
117 0.8980 0.7840 0.6837 -5.18 4.56
118 0.8734 0.7618 0.6637 -5.24 4.61
119 0.8495 0.7404 0.6445 -5.30 4.66
120 0.8263 0.7196 0.6258 -5.36 4.71
Pipe Sensor
R25 =10Kȍ±3%ć
B25 /50 =3700K±3%ćć
Temp.((ć))
Max.(Kȍ) Normal(Kȍ) Min.(Kȍ)
Tolerance(ć)
-30 165.2170 147.9497 132.3678 -1.94 1.75
HSU-07 09 12L HEK03
24
