Haier HSU-12LEK03 [62/86] Removal of front panel

Removal of Front Panel

Please close the panels

before start the removal

procedure of front grille.

Slide the front panel from

one side to another to

release each axis.

Open the front panel

until it is on the

horizontal position,

and then release the

pivots on both sides of

the unit to remove the

front panel.

Removal Procedure

HSU-07 09 12L HEK03
