)XQFWLRQVDQGFRQWURO
'RPHVWLF$LU&RQGLWLRQHU
+68 /+(.
37 14.0599 13.3650 12.6889 -1.20 1.16
38 13.4786 12.7957 12.1325 -1.23 1.20
39 12.9244 12.2537 11.6035 -1.27 1.24
40 12.3960 11.7375 11.1004 -1.31 1.27
41 11.8921 11.2459 10.6218 -1.35 1.31
42 11.4113 10.7775 10.1665 -1.39 1.34
43 10.9526 10.3311 9.7330 -1.43 1.38
44 10.5147 9.9056 9.3204 -1.48 1.42
45 10.0967 9.4999 8.9275 -1.52 1.45
46 9.6976 9.1130 8.5532 -1.56 1.49
47 9.3163 8.7439 8.1965 -1.60 1.53
48 8.9521 8.3916 7.8566 -1.64 1.57
49 8.6040 8.0554 7.5327 -1.68 1.60
50 8.2713 7.7345 7.2237 -1.73 1.64
51 7.9531 7.4280 6.9291 -1.77 1.68
52 7.6489 7.1353 6.6480 -1.81 1.72
53 7.3580 6.8556 6.3797 -1.85 1.76
54 7.0796 6.5884 6.1237 -1.90 1.79
55 6.8131 6.3329 5.8793 -1.94 1.83
56 6.5581 6.0887 5.6459 -1.99 1.87
57 6.3140 5.8552 5.4230 -2.03 1.91
58 6.0802 5.6318 5.2100 -2.07 1.95
59 5.8563 5.4181 5.0065 -2.12 1.99
60 5.6417 5.2136 4.8120 -2.16 2.03
61 5.4361 5.0178 4.6260 -2.21 2.07
62 5.2391 4.8304 4.4481 -2.25 2.11
63 5.0502 4.6510 4.2780 -2.30 2.15
64 4.8691 4.4791 4.1153 -2.35 2.19
65 4.6954 4.3145 3.9596 -2.39 2.23
66 4.5287 4.1567 3.8105 -2.44 2.27
67 4.3689 4.0055 3.6678 -2.49 2.31
68 4.2154 3.8605 3.5312 -2.53 2.35
69 4.0682 3.7216 3.4004 -2.58 2.39
70 3.9268 3.5883 3.2750 -2.63 2.43
71 3.7910 3.4605 3.1549 -2.68 2.48
72 3.6606 3.3378 3.0398 -2.73 2.52
73 3.5353 3.2201 2.9294 -2.77 2.56
74 3.4150 3.1072 2.8237 -2.82 2.60
75 3.2993 2.9987 2.7222 -2.87 2.64
76 3.1881 2.8946 2.6249 -2.92 2.68
77 3.0812 2.7946 2.5316 -2.97 2.73
78 2.9785 2.6986 2.4420 -3.02 2.77
79 2.8796 2.6063 2.3560 -3.07 2.81
80 2.7845 2.5176 2.2735 -3.12 2.86
81 2.6931 2.4324 2.1943 -3.17 2.90
