ECS Elitegroup BSWI-D2-J3060M [8/63] Bswi d2 user manual
![ECS Elitegroup BSWI-D2-N3050 [8/63] Bswi d2 user manual](/views2/1806693/page8/bg8.png)
3
BSWI-D2 USER MANUAL
Chapter 1
System BIOS
Form Factor
• Mini ITX Size, 170mm x 170mm
• AMI BIOS with 64Mb SPI Flash ROM
- Supports Plug and Play
- Supports ACPI & DMI
- Supports STR (S3) /STD (S4)
- Supports Hardware monitor
- Audio, LAN, can be disabled in BIOS
Ap/ Bundled
Software
Support
- F7 hot key for boot up devices option
- Supports PgUp clear CMOS Hotkey (Has PS2 KB Model only)
Note: *
1
Microsoft .NET Framework 3.5 is required.
*
2
Free bundle software is including ECS DVD: Cyberlink Media
Suite.
• Supports eBLU*
1
/eDLU/eSF
• 3rd Party Bundled Software: Cyberlink Media Suite*
2
