ECS Elitegroup LIVA ZE [13/76] Liva z plus mini pc user manual

LIVA Z PLUS MINI PC USER MANUAL

Chapter 1

• 3 x Type-A USB 3.0 ports and 1 x Type-C

USB 3.0 port

• 1 x Power button

• 1 x Audio combo jack

• 1 x Front USB 2.0 header

• 1 x 2-pin Front LED header

• 1 x 2-pin battery connector

• 1 x 3-pin System Cooling Fan connector

• 1 x 4-pin Digital Microphone connector

• 2 x M.2 slots

• 1 x Mini PLUS connector (LPC_CONN)

• 1 x HDD connector (SATA_CONN)

• 4 x RS232 connectors (COM1~4) (With

COM Port Card)

Internal I/O

Connectors &

Headers

Power Supply

• Adapter 19V, 65W

Dimension

• 117mm x 128mm x 32mm

VESA

• 100mm x 100mm
