ECS Elitegroup LIVA ZE [7/76] Liva z plus mini pc user manual

LIVA Z PLUS MINI PC USER MANUAL

vii

Canadian Department of Communications

This class B digital apparatus meets all requirements of the

Canadian Interference-causing Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences

du Réglement sur le matériel brouilieur du Canada.

The manual consists of the following:

Describes features of the

PC.



page 1



page 11

Introducing the PC

Provides information on

using the BIOS Setup

Utility.

About the Manual

Chapter 1

Chapter 2

Using BIOS

Describes the

motherboard software.

Chapter 3

Using the Motherboard Software



page 49

Provides basic trouble

shooting tips.

Chapter 4

Troubleshooting



page 61
