![Haier HSU-09LV03 [22/34] Thermister resistance chart](/views2/1807362/page22/bg16.png)
Air Conditioner
room temperature sensor
T(ć) R(K¡)
-20 251.8
-19 236.9
-18 223.1
-17 210.1
-16 197.9
-15 186.5
-14 175.9
-13 165.9
-12 156.5
-11 147.7
-10 139.5
-9 131.8
-8 124.5
-7 117.7
-6 111.3
-5 105.3
-4 99.63
-3 94.3
-2 89.3
-1 84.58
0 80.14
1 75.96
2 72.02
3 68.31
4 64.81
5 61.51
6 58.39
7 55.45
8 52.68
9 50.06
10 47.58
11 45.24
12 43.02
13 40.93
14 38.95
15 37.08
16 35.31
17 33.63
18 32.04
19 30.53
THERMISTER RESISTANCE CHART
Edition:2006/8/20
1
THERMISTER RESISTANCE CHART
Edition:2006/8/20
18
