Haier HSU-09LV03 [23/34] Thermister resistance chart
![Haier HSU-09LV03 [23/34] Thermister resistance chart](/views2/1807362/page23/bg17.png)
Air Conditioner
Edition:2006/8/20
21 27.75
22 26.47
23 25.25
24 24.1
25 23.00
26 21.96
27 20.97
28 20.03
29 19.14
30 18.3
31 17.49
32 16.73
33 16
34 15.3
35 14.65
36 14.02
37 13.42
38 12.85
39 12.31
40 11.79
41 11.3
42 10.83
43 10.39
44 9.96
45 9.553
46 9.165
47 8.794
48 8.441
49 8.103
50 7.78
51 7.472
52 7.178
53 6.897
54 6.628
55 6.371
56 6.125
57 5.889
58 5.664
59 5.449
60 5.243
61 5.046
62 4.857
19
THERMISTER RESISTANCE CHART
