Haier HSU-09LV03 [24/34] Thermister resistance chart
![Haier HSU-09LV03 [24/34] Thermister resistance chart](/views2/1807362/page24/bg18.png)
Air Conditioner
64 4.502
65 4.336
66 4.177
67 4.024
68 3.878
69 3.738
70 3.603
71 3.474
72 3.35
73 3.231
74 3.117
75 3.008
76 2.903
77 2.802
78 2.705
79 2.611
80 2.522
INDOOR PIPE
TEMPERATURE SENSOR
T(ć) R(K¡)
-20 87.42
-19 82.71
-18 78.29
-17 74.12
-16 70.21
-15 66.52
-14 63.06
-13 59.79
-12 56.71
-11 53.81
-10 51.08
-9 48.5
-8 46.07
-7 43.77
-6 41.6
-5 39.55
-4 37.62
Edition:2006/8/20
20
THERMISTER RESISTANCE CHART
