Haier HSU-09LV03 [26/34] Thermister resistance chart
![Haier HSU-09LV03 [26/34] Thermister resistance chart](/views2/1807362/page26/bg1a.png)
Air Conditioner
Edition:2006/8/20
41 5.287
42 5.09
43 4.902
44 4.722
45 4.549
46 4.383
47 4.225
48 4.073
49 3.927
50 3.788
51 3.654
52 3.525
53 3.402
54 3.283
55 3.17
56 3.061
57 2.956
58 2.855
59 2.759
60 2.666
61 2.577
62 2.491
63 2.408
64 2.329
65 2.253
66 2.179
67 2.108
68 2.04
69 1.975
70 1.912
71 1.851
72 1.793
73 1.737
74 1.682
75 1.68
76 1.58
77 1.531
78 1.484
79 1.439
80 1.395
22
THERMISTER RESISTANCE CHART
