Commercial Air Conditioner
There is no shield time for high pressure protection, the system will check the high pressure after
compressor run, if the signal cut-off lasts more than 30 seconds, compressor and outdoor motor will
stop and 3 minutes later it will resume. If within 30 minutes there are stop phenomenon 3 times
because of pressure over high, the compressor will stop and LCD will display E6. only shut off and
powered on again, the protection can be cancelled. Check the high pressure in standby and deforst
mode, failure will be indicated if the signal cut-off lasts more than 30 seconds.
3.5.2 Low pressure protection
(1) Check the pressure switch immediately when compressor is start, the compressor will stop if
signal cut-off lasts for 30 seconds, if cut-off 3 times continuously in 30 minutes, compressor will stop
and alarm.
(2) In heating, low pressure switch will be shielded in 10 minutes after the compressor start.
(3) In defrosting, low pressure switch will not be checked. In 5 minute after defrost is over, check the
low pressure switch. Check the low pressure switch during standby mode, the compressor will not
start if low pressure switch activate during standby, compressor will stop and indicate low pressure
failure if low pressure switch has acteivated for 30 seconds.
(4) Failure will occur if low pressure switch opens 3 times continuously in 30 seconds, failure can be
resumable when power-off.
3.6 3-minutes protection for compressor
After compressor stops, it cannot be started until 3 minutes later. During the machine’s running,
if the time not more than 3 minutes after power is off, the compressor cannot be restarted until 3
minutes later after it is powered on again
3.7 Sensor broken down protection
a. Check if sensor breaks down
Outdoor board checks the sensor in short circuit or in open circuit or near to short/open circuit for 2
minutes continuously, then it will adjust the sensor broken down.
b. How to deal with it?
If the outdoor ambient temp. sensor, the outdoor coil temp. sensor and dicharge temp. sensor have
broken down, the unit will stop running, and alarm E3, E4, E4 simultaneously.
The discharge temp. sensor will check after compressor run, compressor will stop if temp. higher
than 120℃ after 2 minutes and 3 minutes later it will resume if temp. lower than 95℃. If within 30
minutes the discharge temp. over 120℃ occurs 3 times, the compressor will stop and LCD will
display E4. only shut off and powered on again, the system can be resumed. The compressor will
stop and LCD will display E4 if check the signal short-connect over 2 minutes. After the compressor
has started 3 minutes, dectect the open-circute, The compressor will stop and LCD will display E4 if
signal open 2 minutes continuously. Dicharge temp. failure is resumable when given corrective
signal. Outdoor ambient and coil temp. sensor can be used during motor control and deforst
control.
3.8 Starting current control
Outdoor unit load control: after the outdoor motor running for 2 seconds, main compressor start
up, the secondary compressor will run 2 seconds later.
3.9 4-way valve control
4. Outdoor PCB test
(1) There are three pins marked with TEST, please make the two ones near to COOL in short circuit.
Outdoor begin to run in cooling mode, that is, compressor run and outdoor motor works at high
18
Model: HCFU-42CH03
HCFU-42HK03
