Commercial Air Conditioner
3
1.1. Products code explanation
1.2 Brief Introduction for T1、T2、T3 working condition
Climate type
Type of Air
Conditioner
T1 T2 T3
Cooling Only
18 ℃~43℃ 10℃~35℃ 21℃~52℃
Heat pump
-7℃~43℃ -7℃~35℃ -7℃~52℃
Electricity Heating
~43℃ ~35℃ ~52℃
1.3 Operating Range of Air Conditioners
Temp. Mode Rated Maximum Minimum
DB ℃
27 32 18
Indoor
WB ℃
19 23 14
DB ℃
35 43 10
Cooling
Outdoor
WB ℃
24 26 6
DB ℃
20 27 15
Indoor
WB ℃
14.5 --- --
DB ℃
7 24 -7
Heating
Outdoor
WB ℃
6 18 ---
Applicable voltage: 03 stands for 200-220V/50Hz
Design number
Product type: H stands for heat pump type, C stands for cool
only type, E stands for electric heating type
Cooling / Heating capacity,18=18000BTU/h
Product type : “B” stands for cassette type, “CF” stands for
convertible type, ”D” stands for duct, “P” stands for cabinet
type, ”Q” stands for chiller system, "E" stands for ceiling
concealed type, “U” stands for outdoor unit
Haier
1. DESCRIPTION OF PRODUCTS & FEATURES
H CFU---42 C H 03
Model: HCFU-42CH03
HCFU-42HK03
