7
03/2012
Socket driver (8 mm), (10 mm)
Cross-shaped screwdriver
Putty knife or thin-blade screwdriver
1) Remove the three screws at the rear and the two
screws at the top of the Larder Freezer and remove
the lid.
5) Lay the Upright Freezer backward. Remove
the bottom hinge bracket using an 8 mm socket or
spanner.
2) Use an 8 mm spanner to remove the top bracket.
6) Remove the pin and replace on the opposite side.
Using a 10 mm socket or spanner.
Reattach bottom bracket to the Upright Freezer. Re-
place leveling feet. Stand upright and replace door.
3) Lift the hinge bracket out of the recess in the door.
7)
Insert top
hinge bracket into the recess o
n
top of the
door. Bolt into place using the three bolts removed earli-
er.
4) Remove the pin from the bracket with a 10mm
spanner/socket. Replace in the same hole
through the other side. Remove the door.
8) Remove blanking plates from the door handle to
reveal screws. Remove the two screws that secure the
handle,
