HBU-24H03 HBU-28HD03 Part l
No. Part name Specialized number QTY.
1 front guard grill assy. 001A0100122 1
2 handle 001A1436160 2
3 front panel 001A0100261 1
4 service panel 001A0100524 1
5 axial fan 001A5402022 1
6 outdoor motor 001A3000202 1 *
7 motor bracket 001A0100530 1
8 condenser assy. 001A0400139 1
9 electrical box 001A1301453 1
10 fan capacitor 001A3600018 1 *
11 connection block 001A4000011 1
12 runing capacitor 001A3600030 1 *
13 clip of capacitor 0010100001 1
14 AC contactor 001A3900161 1 *
15 terminal block 001A4000151 1
16 power connection block 001A4000110 1
17 wire clip 001A5731054 1
18 gas discharge tube assy. 001A0500368 1
19 gas charge tube assy. 001A0500433 1
20 filter 001A2411023 1
21 3-way valve 001A2500083 1 *
22 2-way valve 001A2500082 1 *
23 muffle 001A2111911 1
24 compressor 001A2000201 1 *
25 partition plate 001A0100350 1
26 top cover plate 001A0100264 1
27 back guard grill 001A0100109 1
28 wiring box cover 001A0100394 1
29 right plate assy. 001A0100390 1
30 valve seat 001A1301506 1
31 arm 001A1301117 2
32 bottome plate assy. 001A0100351 1
33 wiring harness 001A4400742 1
HBU-28HD03
24 compressor 0010700989 1
ist of outdoor unit
Remark
