Haier HBU-18HC03 [83/98] Exploded views parts lists
![Haier HBU-18HC03 [83/98] Exploded views parts lists](/views2/1808728/page83/bg53.png)
HBU-36H03 HBU-42HD03 Part list of panel
No. Part name Specialezed number QTY. Remark
1 corner cover 0100505 3
2 inlet grill 1232241 1
3 air filter 2400110 2
4 spring 5501056 2
5 lift switch(right) 1446847 1 *
6 lift switch(left) 1446846 1 *
7 fix clamp of air filter 1433845 4
8 stator of corner cover 1301654 8
9 panel 1232242 1
10 cushion 1 17341107 2
11 foamy cushion 1 1742025 6
12 cushion 2 17341104 2
13 cushion 3 17341106 2
14 foamy cushion 2 1742026 2
15 foamy cushion 3 17561169 2
16 connection 1443835 6
17 inner corner cover assy.2 17421163 1
18 cushion 4 1742016 1
19 fan blade assy.2 0100503 2
20 inner corner cover assy.3 0100665 1
21 cushion 5 17421072 1
22 cushion 6 1742018 1
23 inner corner cover assy.4 0100666 1
24 oriented cam 1431840 1
25 box of synchronous motor 1436839 1
26 synchronous motor 3000196 1
27 cushion 7 1742015 1
28 inner corner cover assy.1 0100663 1
29 connecting rod 1443834 3
30 link piece 2 1443837 6 *
31 link piece 1 1431836 8 *
32 link piece 3 1443838 8 *
33 fan blade assy.1 0100502 2
34 fix plate assy. 0100631 2
35 fortified tendon 2 1301653 2
36 cushion 8 17561167 2
37 cushion 9 17561281 2
38 cushion 10 17561168 2
39 frame of outlet grill 2 1433851 2
40 frame of outlet grill 1 1433850 2
41 cushion 11 17561170 1
42 cushion 12 17341105 2
43 fortified tendon 1 1301652 2
44 ring assy. 0100506 4 *
45 fortified tendon 3 1301655 1
46 magnet 1300727 8 *
47 nylon list 17451115 4
- 83 -
EXPLODED VIEWS & PARTS LISTS
