To Keep Your Air conditioner in Good Condition
after Season.
Operate in cooling mode for 2-3 hours.
Put off the power supply cord.
Take out the batteries from the
wireless remote controller.
Cleaning the body.
To prevent breeding mold or bad smell, be sure to
operate at the designated temperature or 30
O
C,cooling
mode and High speed fan mode for 2-3 hours.
Maintenance
47
