Installations
65
Domestic Air Condition
Installation manual
1.The main unit installation
According to the drawing, install the full energy recovery exchanger on
the corresponding place of the outdoor unit, and fix the fittings on the
outdoor unit cover with the screws.
Fresh air exit
D
E
A
C
B
Room air entrance,
connect room air pipe
Fresh entrance
Fresh air filter
Room air exit
Fixation screw
Outdoor unit
HSU-09,12H03/R(QXF)
