Bomann GSPE 787 [24/31] Dishwasher installation steps
![Bomann GSPE 787 [24/31] Dishwasher installation steps](/views2/1081009/page24/bg18.png)
6
5
7
2
RUBBER
SCREW
COVER
8
SCREW
CONE GEAR
6B
6A
【】Figure 7
Dishwasher installation steps
●
.
.
.
.
7
8
1 Install the furniture door to the outer door ofthe dishwasher using the brackets
provided. Referto thetemplate forpositioning of thebrackets.
2 Adjust the tension ofthe door springs by using anAllen key turning in a clockwise
motion totightenthe left and right door springs. Failure to do thiscouldcausedamage
toyour dishwasher (Illustration 2)
3 Con ne ct t h e inl et h ose to the cold water s uppl y
4 Con nec tt he d ra in hose . Refer to diag ra m (Fi gure 6 )
5 Con nec tt he power co rd
Affix thecondensation strip under theworksurface of cabinet. Please ensure
the condensation stripis flush with edgeof work surface.
Place the dishwasher into position .
Level the dishwasher. Therear feet can be adjusted fromthe front of the dishwasher
by turn ing th e s cr ews on th ele ft a nd r ight ha nd s ide of the ca bin et (Il lust ration 6A ).
To adjust the front feet, use a wrench and turn the front feetuntil the dishwasher is level
(Illust ration 6B).
9 Thedishwasher must be securedin place.There are two ways to do this:
A. Nor mal work surface-secure to the work surface by using two woodscrewsensuring
the dishwasher weight is notbeinghit bythe surface(Illustration 7).
B. Ma rble or grani te wor k top- secure t he b racke t to t he s ide pan el o f the d ishw as her
and secure the dishwasherto the furniture housing. Put the rubber cap over the screw
(Illustra tion 8) .
6
