Installation
3. Diagram of arrangement of multiple chiller units
Cut-off height of
top ventilation
>3000
Space between
units and wall>450
Space between
units and
wall>1000
Space
between
units >450
Space
between
units >450
Space
between
units >450
Space
between
units >900
Space
between
units >900
Space
between
units >900
Unit
height
