Haier CA0130EAND [41/42] Technical parameters
![Haier CA0130EAND [41/42] Technical parameters](/views2/1813182/page41/bg29.png)
39
13. Technical Parameters
■ Correction factor
Cooling:
Water outlet
temperature
(°C)
Ambient temperature (°C)
25 30 35 40 45
kW
Cooling
capacity
Cooling
capacity
Cooling
capacity
Cooling
capacity
Cooling
capacity
5 1.07 1.00 0.94 0.94 0.81
7 1.14 1.07 1.00 0.96 0.86
9 1.20 2.13 1.06 0.98 0.91
11 1.27 1.19 1.12 1.04 0.96
13 1.34 1.26 1.17 1.09 1.01
15 1.41 1.32 1.23 1.14 1.06
Heating
Water outlet
temperature
(°C)
Ambient temperature (°C)
15 10 7 5 0 -5 -10 -15
kW
Heating
capacity
Heating
capacity
Heating
capacity
Heating
capacity
Heating
capacity
Heating
capacity
Heating
capacity
Heating
capacity
30 1.26 1.16 1.12 1.07 0.88 0.82 0.72 0.69
35 1.24 1.15 1.11 1.06 0.88 0.81 0.71 0.69
40 1.22 1.14 1.10 1.05 0.87 0.80 0.71 0.67
45 1.19 1.12 1.00 1.03 0.85 0.79 0.70 0.66
50 1.19 1.11 1.07 1.02 0.84 0.78 0.67 0.65
55 1.14 1.07 1.03 0.98 0.83 0.77 - -
