Item

CA0130EAND

Nominal refrigerating capacity kW 130

Nominal heating capacity kW 135

Nominal refrigerating input power kW 19.1

Nominal heating input power kW 19.2

Max. input power kW 28

Max. operating current A 55

Compressor

Type -- Flexible scroll compressor

Qty. EA 4

Rated power kW 18.3

Capacity regulating range --- 50%, 100%

Refrigerant

Type --- R410a

Charge kg 5.8*4

Refrigerant throttling device --- Electronic expansion valve

Power supply type --- 3N~, 380V, 50Hz

Air-side heat

exchanger

Type --- Slit n + efcient inner grooved copper tube

Fan type --- Axial ow fan

Fan power kW 1.5

Qty. EA 4

Waterside

heat

exchanger

Type --- Shell tube heat exchanger

Flow m³/h 24

Water pressure loss kPa 60

Connection dimension --- 2’’

Scaling factor m² · °C/kW 0.018

Standard pressure-bearing Kpa 1

Net

dimensions

Length x Width x Height mm 2000x1603x2120

Weight

Net weight kg 1100

Operating weight kg 1150

Safety

protection

High/low pressure protection, water-break delay protection, anti-freezing protection, motor

overload, overheating protection, phase failure and phase sequence protection.

Note:

1. Nominal refrigerating condition: water outlet temperature is 7°C, ambient temperature is 35°C, and water ow

is 0.172[m³/(h · kW)].

2. Nominal heating condition: water outlet temperature is 45°C, ambient temperature is 7°C for dry bulb and 6°C

for wet bulb, and water ow is listed in the above table.

3. Unit operating range: conforming to GB/T 18430.1.

4. Scaling factor of circulating water: 0.018m² ·°C/kW.

5. The specications in the table may vary with changes in product design without prior notice.
