10 11
1. Door
2. Detergent/Softener drawer
3. Wor ktop
4. Control panel
5. Service flap
6. Adjustable feet
Product description
Control Panel
Accessories
Check the accessories and literature in a ccordance with this list.
2. Display
3. programme selector
4. Power button
5. Function buttons (a-g)
(a-g)
1.2 Programme selector
1. Transportation bolts (T1-T4)
2. Back cover
3. Back cover screws(S1-S6)
4. Power cord
5. Water inlet valve
6. Drain hose
This drawing may be slightly different from the layout of the washing machine you have
just purchased.
S5 S6
Inlet hose
assembly
Warranty-card
5 blanking plugs
User manual
Drain hose
brac ket
1. De
tergent/Softener drawer
a. Delay
c. Wash Temp
d. Spin Speed
e. Extra Rinse
f. Time/Air Dry
g. Start/Pause
Time/Air
Dry
Dry Spin
Speed
Extra
Rinse
Delay Start/PauseWash
Temp
8kg / 4kg
Wash + Dry
Dry
Wash
On / Off
Wash
Dry
Time/Air
Dry
Dry Spin
Speed
Extra
Rinse
Delay Start/PauseWash
Temp
8kg / 4kg
Wash + Dry
Dry
Wash
On / Off
Wash
Dry
1.1 Detergent drawer
Open the drawer, three compartments can be
seen :
1
Compartment : Liquid detergent for programme
2
Compartment : Softener, Conditioning agent etc.
3
Compartment : Powder detergent for programme
By turning the knob , one of 16 programmes can be selected,
be displayed.
Touch this button gently to switch on, the display is shining.
a while, the machine will shut down automatically.
Touch it again for
its default settings will
1-1
1
2
3
1.3 Power button
about 2 seconds to switch off. If no panel element or
prog
r
amme is
activated after
Noise reduction pads
2x
2x
