![Haier HWD8040BW1 [7/14] Note liquid detergent](/views2/1813885/page7/bg7.png)
12 13Control panel-function buttons
Display symbolsControl panel-
Note: Liquid detergent
If using liquid detergent, it is not recommended to activate the end time delay.
1.4.2 Function “Time/Air Dry”
1-3
1-5
1.4 Function buttons
The function buttons (Fig. 1-2) enable additional op-
tions in the selected programme before programme
start. The related indicators are displayed.
If a button has multiple options, the desired option can
be selected by touching the button sequentially.
To delete the setting or to cancel the setting process,
press the function button,
Not all functions are available for all programmes.
1-2
Note: Factory settings
there is no special requirement default settings are recommended.
Touch this button (Fig. 1-4) in order to activate /de-
activate the “Time/Air Dry” function.
By touching button sequentially, drying time can be seen
In combination with programme
function
sets
the drying time.
1-4
Time/Air
Dry
Dry Spin
Speed
Extra
Rinse
Delay Start/PauseWash
Temp
On / Off
1-6
Start/Pause
Time/Air
Dry
Extra
Rinse
Spin
Speed
1.4.1“Start/Pause“ button
Touch this button (Fig. 1-3) gently to start or inter-
rupt the currently displayed programme.
the displayed washing time is blinking.
During a pause also the time display is blinking.
1.4.3 Function button“Extra rinse“
Touch this button (Fig. 1-5) to rinse the laundry more
intense with fresh water. This is recommended for
people with sensitive skin.
By touching the button several times one to three ad-
ditional cycles can be selected. They appear in the dis-
play with P--0/ P--1 /P--2/P--3.
1.4.4 Function “Spin Speed”
Touch this button (Fig. 1-6) to change or deselect the
Spin Speed of the programme. If 0 is chosen ,then the
laundry will not spin.
1.4.8 Function “child lock”
This option blocks all panel elements against activa-
tion. After programme start press button “Delay” and
”Dry On/Off” (Fig. 1-10) for 3 seconds simultaneous-
ly; “cLok” is displayed. For unlocking press again the
two buttons.
1.4.6 Function “Dry On/Off”
Dry
On / Off
Delay
1-7
1-8
Wash
Temp
1-9
1-10
DryDelay
On / Off
1.4.5 Function “Wash Temp”
Touch this button (Fig. 1-7) to change the washing
temperature of the programme.
In conjunction with the “Delay”button,the child lock
function can be switched on/off (see child lock).
Delay
1.4.7 Function “Delay”
Touch this button (Fig. 1-9) to start the programme
with a delay. End time delay could be increased in steps
6:30
Touch “Start/Pause” button to activate
the time delay.
The time delay must be longer than the programme run
time. Otherwise the programme will start immediately.
For deactivating the time delay; rotate programme se-
lector.
In conjunction with the “Dry On/Off”button,the child lock
function can be switched on/off (see child lock).
Knob is in the "Dry+Wash" area, Perform default settings;
Touch "Dry On/Off " button (Fig. 1-8),dry function will be
switched off and only perform wash function.
1.5 Display
If the appliance is on display will light up the actual
washing time, spin speed, tempe rature, etc will appear
(Fig. 1-11).
Time/Air
Dry
Dry Spin
Speed
Extra
Rinse
Delay Start/PauseWash
Temp
On / Off
Wash
Dry
1-11
“Time/Air Dry”, this
the LED switches off.
means the cycle will finish in 6 hours and 30 minutes
During ope-
ration,
.
By switching off the appliance, all options are disabled.
status on different sections. The information include
