TYI-AS4090 Part List

Date : 2010/07/21

ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY

1 US05080B-12 UM.HD.BOLT 1 34 12103401 TRIGGER VALVE HEAD 1 78 HS05080B-10 HEX.SOC.HD.BOLT 4

2 20900201 EXHAUST COVER 1 35 12103501 TRIGGER VALVE STEM 1 79 E40907903-1 PLATE, NOSE 1

3 20900301 PU WASHER 1 37 OR10719N O-RING 1 80 H32978001 WASHER BUSHING (L) 2

4 HS05080BW-25 HEX.SOC.HD.BOLT+SW 6 38 12103801 TRIGGER VALVE GUIDE 1 81 F32978101 FOOT 2

5 SS04070B-06 SET SCREW 1 39 12104001 TRIGGER 1 82 KHS04070BW-16 HEX.SOC.HD.BOLT+SW 2

6 20900601 CAP 1 43 FH04070B-16 FLAT.HD.BOLT 2 86 F40908601 GUIDE, FRONT 1

7 20900701 PISTON STOPPER 1 46 25604602 NOSE 1 87 H40908702 WASHER BUSHING 2

8 OR11824N O-RING 1 47 11304701 SET PLATE 1 88 KMS05080B-40 HEX.SOC.HD.BOLT 2

9 20900901 COLLAR 1 48 12504801 SET PLATE 1 89 KLN0500N LOCK NUT (M5) 2

10 OR40025N O-RING 3 49A 25604901A STAPLE GUIDE UNIT 1 90 KHS05080B-10 HEX.SOC.HD.BOLT 2

11 20901101 SPRING 1 50 12505004 MAGAZINE 1

12 20901201 PISTON HEAD VALVE 1 51 12505101 PUSHER 1

13 20901301 STOPPER 1 52 11205201 SLIDE BLOCK 2

14 OR31735N O-RING 1 53 11305301 SPRING 2

15 OR28235N O-RING 1 54 11305401 ROD 2

16A 22801602A DRIVER ASSEMBLY 1 56 11305601 SET BLOCK 2

17 20901701 CYLINDER 1 57 HS04070B-08 HEX.SOC.HD.BOLT 2

18 OR37530N O-RING 1 58 12505802 END CORE 1

19 20901901 BUMPER 1 59 13908102 STOPPER 1

20 20902001 GASKET 1 60 32906001 SPRING 1

21 OR01919N O-RING 2 62 13908401 STEPPED PIN 1

22 22902201 BODY 1 63 HS04070B-10 HEX.SOC.HD.BOLT 2

23 HS05080B-12 HEX.SOC.HD.BOLT 1 64 10206201 STEPPED PIN 1

24 12106401 AIR PLUG 1 65 11009101 TOR. SPRING 1

25 12502501 JOINT GUIDE 1 66 11002801 TRIGGER 1

27 ER0250R E-RING 2 67 12103901 SPRING 1

32 11103201 STEPPED PIN 1 68 12506802 SET PLATE 1

33 12103301 SEAL 1 69 12706901 BRACKET 1

Note : When ordering spare parts, please state Item No., Part No. and Description.
