![Haier ESA3125 [3/24] Product code illumination and series introduction](/views2/1818693/page3/bg3.png)
Domestic Air Conditioner Model: HWR10XC5 HWR10XC5-T
HWR12XC5 ESA3105 ESA3125
2
Product Code Illumination And Series Introduction
1.Model identification:
H W
A B C D E F G
A: Abbreviation of Haier
B: Abbreviation of Window
C: R-Remote Control
F-Mechanical Control
D: Nominal cooling capacity(BTU/h) with the first two numbers based on one
thousand unit
E: The type of power supply
X: 115V/60HZ
V:208/220V/50HZ
F: Function code
C-Cooling only
H-Heating pump
E-Electric aided heating
G: Design code
Examples:
HWR10XC5
It represents remote contrl window air conditioner.Cooling capacity is 10000BTU/h and
the power supply is 115V /60Hz.
2.Standard situation/conditions
Indoor air state outdoor air state
No.
Operating condition
D.B.℃ W.B.℃ D.B.℃ W.B.℃
1 Nominal cooling 26.7 19.4 35 23.9
2 Nominal heating / / / /
3
Nominal electrical
heating
/ / / /
