Domestic Air Conditioner Model: HWR10XC5 HWR10XC5-T
HWR12XC5 ESA3105 ESA3125
3
Specifications:
Item UNIT HWR10XC5,HWR10XC5-T HWR12XC5
Cooling capacity BTU/h
10000 12000
Heating capacity BTU/h
/ /
Power supply
1PH/115V/60Hz 1PH/115V/60Hz
Power input
W 1020 1220
Running current
A 9.0 10.6
Cooling
EER
BTU/(hW) 9.8 9.8
Power input
W / /
Running current
A / /
Heating
COP
BTU/(hW) / /
Indoor side dB(A)
/ /
Sound Level
Outdoor side dB(A)
/ /
Height
mm
380 380
Width
mm
600 600
Case
Depth
mm
570 570
Height
mm
470 470
Width
mm
643 643
Packaging
dimensions
Depth
mm
613 613
Net kg
36.5 40
Weight
Gross kg
40 40.5
Type
Rotate Rotate
Model
44R241A 44R291A
Running cap. for comp.
μ
F
60µF / 250 VAC 60µF / 250 VAC
Compressor
Starting method
PSC PSC
Heating side Psig
380 380
Pressure
Cooling side Psig
170 170
Model
R22 R22
Refrigerant
Charge kg
0.61 0.67
indoor unit
Acentric fan
Acentric fan
Type
outdoorunit
Axial fan Axial fan
indoor unit r/min
1050
±
30/1000
±
40/950
±
40 1050
±
30/1000
±
40/950
±
40
Fan
Fan
speed
outdoorunit r/min
1050
±
30/1000
±
40/950
±
40
1050
±
30/1000
±
40/950
±
40
Air volume CFM
520 520
Moisture removal M
3
/h
2.0ⅹ10
-3
2.0ⅹ10
-3
Exchanging pipe type/ diameter mm Evaporator
:φ7 condenser:
φ7
Evaporator
:φ7 condenser:
φ7
Fin material
Hydrophile aluminum foil Hydrophile aluminum foil
